Номер на схеме |
Каталожный номер |
Название |
Количество |
Детали |
|
|
|
? |
C1614 |
CAPSCREW - 1/2" - 13NC X 1 1/2" |
20 |
|
|
|
|
? |
C1540 |
LOCKWASHER - 1/2" |
36 |
|
|
|
|
? |
TF3231 |
CLAMP, SPLIT FLANGE |
12 |
|
|
|
|
? |
WA0187 |
O-RING |
6 |
|
|
|
|
? |
HA7402 |
HOSE |
1 |
|
|
|
|
? |
C1615 |
CAPSCREW - 1/2" - 13NC X 1 3/4" |
12 |
|
|
|
|
? |
VH6718 |
CLAMP, SPLIT FLANGE |
6 |
|
|
|
|
? |
WA0232 |
O-RING |
3 |
|
|
|
|
? |
HA7590 |
HOSE |
1 |
|
|
|
|
? |
HA7602 |
HOSE |
1 |
|
|
|
|
? |
HA6250 |
HOSE |
1 |
|
|
|
|
? |
C1614 |
CAPSCREW - 1/2" - 13NC X 2 1/2" |
8 |
|
|
|
|
? |
HA6253 |
HOSE |
1 |
|
|
|
|
? |
WA5686 |
CLAMP |
1 |
|
|
|
|
? |
WB1002 |
CLAMP |
1 |
|
|
|
|
? |
HA7439 |
HOSE |
1 |
|
|
|
|
? |
HA7442 |
HOSE |
1 |
|
|
|
|
? |
EH1245 |
PUMP/VALVE MODULE (SEE FIG 60285) |
1 |
|
60285 |
|
|
? |
HA7593 |
HOSE |
1 |
|
|
|
|
? |
TF3237 |
CLAMP, SPLIT FLANGE |
2 |
|
|
|
|
? |
VG9095 |
O-RING |
1 |
|
|
|
|
? |
WB0520 |
FITTING, O-RING - 90 DEG |
1 |
|
|
|
|
? |
HA6619 |
HOSE |
1 |
|
|
|
|
? |
HA7438 |
HOSE |
1 |
|
|
|
|
? |
WB0580 |
FITTING, O-RING - STRAIGHT |
1 |
|
|
|
|
? |
TH9942 |
HOSE |
1 |
|
|
|
|
? |
HA6833 |
HOSE |
1 |
|
|
|
|
? |
WA5460 |
CLAMP, TUBE |
1 |
|
|
|
|
? |
TY8367 |
HOSE |
1 |
|
|
|
|
? |
TY8365 |
HOSE |
1 |
|
|
|
|
? |
HA7453 |
HOSE |
1 |
|
|
|
|
? |
C1629 |
CAPSCREW - 5/8" - 11NC X 1 3/4" |
4 |
|
|
|
|
? |
C1541 |
LOCKWASHER - 5/8" |
8 |
|
|
|
|
? |
VL9963 |
CLAMP, SPLIT FLANGE |
2 |
|
|
|
|
? |
WA0237 |
O-RING |
1 |
|
|
|
|
? |
C1630 |
CAPSCREW - 5/8" - 11NC X 2" |
4 |
|
|
|
|
? |
VN7716 |
CLAMP, SPLIT FLANGE |
2 |
|
|
|
|
? |
WA0245 |
O-RING |
1 |
|
|
|
|
? |
WA5629 |
CLAMP, FLANGE |
2 |
|
|
|
|
? |
C1631 |
CAPSCREW - 5/8" - 11NC X 2 1/4" |
4 |
|
|
|
|
? |
VG9096 |
O-RING |
2 |
|
|
|
|
? |
WA5630 |
CLAMP, FLANGE |
4 |
|
|
|
|
? |
HA7587 |
HOSE |
1 |
|
|
|
|
? |
HA7588 |
HOSE |
1 |
|
|
|
