| Наименование | Страница | Код страницы |
|---|---|---|
| DIFF. SWITCH ASSM (RELAY VALVE) BF2876 | 214 | 60117A |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VE9058 | CAPSCREW (1) | 4 | ||||
| ? | BF2590 | WASHER | 4 | ||||
| ? | VE9421 | RETAINER, SLEEVE | |||||
| ? | VE9418 | PLUG | 1 | ||||
| ? | VE9406 | PACKING (1) | 1 | ||||
| ? | VE8088 | SEAL (1) | 2 | ||||
| ? | VE1395 | PLUNGER (1) | 2 | ||||
| ? | EF5752 | SPOOL, REGULATING | 2 | ||||
| ? | VE9415 | SLEEVE (1) | 2 | ||||
| ? | VE9401 | SPRING, SPOOL (1) | 2 | ||||
| ? | BF2597 | SEAT, SPRING | 2 | ||||
| ? | VE9402 | SPRING, REGULATOR (1) | 2 | ||||
| ? | BF2597 | SEAT | 2 | ||||
| ? | BF2893 | PLUNGER | 2 | ||||
| ? | BF2894 | SLEEVE | 2 | ||||
| ? | BF2891 | BODY, VALVE (1) | 1 | ||||
| ? | WA0019 | O-RING | 4 | ||||
| ? | BF2896 | PLUG - #8 SAE | 2 | ||||
| ? | BF2895 | BODY, MANIFOLD | 1 | ||||
| ? | BF2897 | PLUG - #4 SAE | 2 | ||||
| ? | BF2898 | CAPSCREW, SOCKET HD | 2 | ||||
| ? | BF2465 | CONNECTOR ASSEMBLY | 1 | ||||
| ? | BF2876 | DIFFERENTIAL SWITCH ASSEMBLY (SEE INDEX) | 1 | 60117A | |||
| ? | VE9407 | RING, BACKUP (1) | 2 | ||||
| ? | VE8083 | RING, BACKUP (1) | 4 | ||||
| ? | TC9899 | O-RING | 2 | ||||
| ? | BF3557 | SPRING | 2 | ||||
| ? | NOTE: (1) NOT SERVICED SEPARATELY. |
