Каталог Komatsu

Наименование	Страница	Код страницы
HYD/BRAKE CABINET ASSEMBLY 1/2	190	60004

Номер на схеме	Каталожный номер	Название	Количество
?	EG0619	BRAKE CABINET ASSEMBLY (SEE FIG 60004)	1	60004
?	MM0620	CAPSCREW - M12 X 1.75 X 40	4
?	MM0472	LOCKWASHER - M12	12
?	MM0179	NUT - M12 X 1.75	4
?	SM2014	CAP	2
?	MM0062	CAPSCREW - M12 X 1.75 X 60	4
?	MM0472	LOCKWASHER - M12	4
?	HA6397	HOSE	2
?	HA6173	HOSE	2
?	HA5553	HOSE	1
?	WB0386	FITTING, TEE	1
?	HA7386	HOSE	1
?	EF9801	FLAP, RUBBER	1
?	MM0470	LOCKWASHER - M8	4
?	MM0460	FLAT WASHER - M8	3
?	MM0177	NUT - M8 X 1.25	3
?	HA7358	HOSE - TO PORT "LS" (STEERING)	1
?	WB0384	FITTING, TEE	3
?	MM0605	CAPSCREW - M10 X 1.50 X 25	9
?	MM0471	LOCKWASHER - M10	15
?	EF8174	CLAMP	2
?	WB0430	FITTING, BULKHEAD	8
?	EF8177	BRACKET	1
?	WB0432	FITTING, BULKHEAD	1
?	WB0427	FITTING, BULKHEAD	2
?	HA7331	HOSE - TO PORT "B2" (BRAKE)	1
?	HA7389	HOSE - TO PORT "T" (BRAKE)	1
?	HA5569	HOSE - TO PORT "P" (STEERING)	1
?	HA7331	HOSE - TO PORT "P2" (BRAKE)	1
?	HA7382	HOSE - TO PORT "T" (STEERING)	1
?	HA7360	HOSE - TO PORT "PX" (BRAKE)	1
?	HA7331	HOSE - TO PORT "P1" (BRAKE)	1
?	HA7331	HOSE - TO PORT "B1" (BRAKE)	1
?	HA7382	HOSE - TO PORT "L" (STEERING)	1
?	HA5569	HOSE - TO PORT "R" (STEERING)	1
?	TG2568	CLAMP	8
?	VN9913	CLAMP	2
?	TY8375	SPACER	6
?	MM0461	FLAT WASHER - M10	6
?	MM0178	NUT - M10 X 1.50	6
?	TG2960	CLAMP	3
?	MM0714	FLAT WASHER - M12 (HARDENED)	4
?	HA6580	HOSE	1
?	HA7425	HOSE	1

?
