| Наименование | Страница | Код страницы |
|---|---|---|
| BATTERY EQUALIZER BOX ASSM (EJ5855) | 336 | 55501 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VZ0852 | BATTERY | 4 | ||||
| ? | EG3572 | BOX, BATTERY - R.H. | 1 | ||||
| ? | VC1387 | CAPSCREW - 1/2" - 13NC X 1" | 8 | ||||
| ? | TR6008 | FLAT WASHER - 1/2" | 8 | ||||
| ? | TR5445 | LOCKWASHER - 1/2" | 8 | ||||
| ? | CH4126 | CABLE | 1 | ||||
| ? | TC1234 | CAPSCREW - 3/8" - 16NC X 3/4" | 2 | ||||
| ? | TR4436 | FLAT WASHER - 3/8" | 4 | ||||
| ? | TC1233 | NUT - 3/8" - 16NC | 2 | ||||
| ? | EJ5402 | CABLE | 2 | ||||
| ? | CH3837 | CABLE | 1 | ||||
| ? | CH4023 | CABLE | 1 | ||||
| ? | CH3852 | CABLE | 1 | ||||
| ? | TG2568 | CLAMP, VINYL - 7/8" | 13 | ||||
| ? | VN9907 | CLAMP, VINYL - 5/8" | 6 | ||||
| ? | MM0641 | STUD, WELD - M8 X 20 | 13 | ||||
| ? | MM0460 | FLAT WASHER - M8 | 13 | ||||
| ? | MM0470 | LOCKWASHER - M8 | 13 | ||||
| ? | MM0177 | NUT - M8 X 1.25 | 13 | ||||
| ? | CH4304 | CABLE | 1 | ||||
| ? | SD5211 | BUSHING, PIPE | 1 | ||||
| ? | VZ1369 | LOCKNUT, CONDULET | 1 | ||||
| ? | CH4022 | CABLE | 1 | ||||
| ? | CH4125 | CABLE | 1 | ||||
| ? | EG3571 | BOX, BATTERY - L.H. | 1 | ||||
| ? | CH3865 | CABLE | 1 | ||||
| ? | EJ5855 | BOX, BATTERY EQUALIZER (SEE INDEX) | 1 | 55501 | |||
| ? | MM0050 | CAPSCREW - M10 X 1.50 X 35 | 4 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 4 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 4 | ||||
| ? | MM0178 | NUT - M10 X 1.50 | 4 |
