| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | TG5720 | CAPSCREW - 3/8" - 16NC X 1" | 6 | ||||
| ? | TR4436 | FLAT WASHER - 3/8" | 6 | ||||
| ? | EG0594 | FLAP | 1 | ||||
| ? | PC0371 | DISPLAY/TRANSMITTER FUEL GAUGE | 1 | ||||
| ? | PB0707 | FLOAT ARM, FUEL GAUGE | 1 | ||||
| ? | EH1830 | BAR | 1 | ||||
| ? | TC1231 | LOCKWASHER - 3/8" | 12 | ||||
| ? | VA1730 | SWITCH | 1 | ||||
| ? | TV5194 | FITTING, PIPE | 1 | ||||
| ? | SC4970 | FITTING, PIPE | 1 | ||||
| ? | VM5736 | CORD GRIP | 1 | ||||
| ? | EG0606 | PLATE | 1 | ||||
| ? | VW4748 | GASKET | 1 | ||||
| ? | TA9974 | FLANGE ASSEMBLY | 1 | ||||
| ? | TD1809 | CAPSCREW - 1/4" - 20NC X 3/4" | 6 | ||||
| ? | EK7337 | PLATE, ADAPTER | 1 | ||||
| ? | TD0791 | CAPSCREW - 3/8" - 16NC X 1 1/4" | 6 | ||||
| ? | VW6420 | CAP, FUEL | 1 | ||||
| ? | TA1691 | GASKET | 1 | ||||
| ? | C5774 | LOCKWASHER - 1/4" | 6 | ||||
| ? | PC2323 | GASKET | 1 | ||||
| ? | VA1732 | GASKET | 1 | ||||
| ? | VA1733 | MOUNT | 1 | ||||
| ? | VA1734 | PLATE | 1 |
