Номер на схеме |
Каталожный номер |
Название |
Количество |
Детали |
|
|
|
? |
MM0460 |
FLAT WASHER - M8 |
4 |
|
|
|
|
? |
MM0590 |
CAPSCREW - M8 X 1.25 X 12 |
1 |
|
|
|
|
? |
VY8331 |
CLAMP, VINYL - 1/4" |
2 |
|
|
|
|
? |
PC1848 |
COMPRESSOR, AIR CONDITIONING (SEE INDEX) |
1 |
|
55781 |
|
|
? |
TR4436 |
FLAT WASHER - 3/8" (ZINC) |
16 |
|
|
|
|
? |
C1602 |
CAPSCREW - 3/8" - 16NC X 1.00 |
8 |
|
|
|
|
? |
WB3091 |
CLAMP, CUSHION - 11/16" |
5 |
|
|
|
|
? |
MM0461 |
FLAT WASHER - M10 |
8 |
|
|
|
|
? |
MM0178 |
NUT - M10 X 1.50 |
5 |
|
|
|
|
? |
MM0471 |
LOCKWASHER - M10 |
8 |
|
|
|
|
? |
WB3093 |
CLAMP, CUSHION - 1" |
4 |
|
|
|
|
? |
WB1304 |
CLAMP, CUSHION - 9/16" |
1 |
|
|
|
|
? |
MM0607 |
CAPSCREW - M10 X 1.50 X 35 (ZINC) |
3 |
|
|
|
|
? |
C1603 |
CAPSCREW - 3/8" - 16NC X 1.25 |
5 |
|
|
|
|
? |
C1521 |
NUT - 3/8" - 16NC |
6 |
|
|
|
|
? |
EF0317 |
BRACKET, REAR |
1 |
|
|
|
|
? |
PB1255 |
FLAT WASHER - 7/16" |
3 |
|
|
|
|
? |
C5775 |
LOCKWASHER - 7/16" |
3 |
|
|
|
|
? |
H0594 |
CAPSCREW - 7/16" - 14NC X 1.25 |
3 |
|
|
|
|
? |
C1606 |
CAPSCREW - 3/8" - 16NC X 2.00 |
1 |
|
|
|
|
? |
EF0321 |
LINK |
1 |
|
|
|
|
? |
EF0320 |
LINK (W/SPACER) |
1 |
|
|
|
|
? |
HA7185 |
HOSE |
1 |
|
|
|
|
? |
WA1732 |
O-RING - 7/16" |
1 |
|
|
|
|
? |
HA8071 |
HOSE |
1 |
|
|
|
|
? |
WA1733 |
O-RING - 9/16" |
1 |
|
|
|
|
? |
EF0314 |
PLATE, MOUNTING |
1 |
|
|
|
|
? |
PC1831 |
FITTING |
1 |
|
|
|
|
? |
PB9152 |
FITTING |
1 |
|
|
|
|
? |
EJ1087 |
ADJUSTABLE HOLD-DOWN ASSEMBLY (SEE INDEX) |
1 |
|
50388 |
|
|
? |
MM0593 |
CAPSCREW - M8 X 1.25 X 20 (ZINC) |
3 |
|
|
|
|
? |
C1547 |
FLAT WASHER - 3/8" |
4 |
|
|
|
|
? |
PC1119 |
WASHER, RUBBER |
8 |
|
|
|
|
? |
EJ7835 |
GUARD, A/C BELT |
1 |
|
|
|
|
? |
EL4304 |
HARNESS, AIR CONDITIONER |
1 |
|
|
|
|
? |
VZ4843 |
TYRAP |
10 |
|
|
|
|
? |
EF0316 |
BRACKET |
1 |
|
|
|
|
? |
C1523 |
NUT - 1/2" - 13NC |
1 |
|
|
|
|
? |
WA4728 |
FLAT WASHER - 1/2" (HARDENED) (ZINC) |
2 |
|
|
|
|
? |
C1614 |
CAPSCREW - 1/2" - 13NC X 1.50 |
1 |
|
|
|
|
? |
EK2839 |
GUARD |
1 |
|
|
|
|
? |
PC0556 |
V-BELT |
1 |
|
|
|
|
? |
EK2844 |
BRACKET |
1 |
|
|
|
|
? |
VJ9187 |
SLEEVE |
1 |
|
|
|
|
? |
MM0470 |
LOCKWASHER - M8 |
4 |
|
|
|
