| Наименование | Страница | Код страницы |
|---|---|---|
| JUNCTION BOX ASSEMBLY - REAR (EK7631) | 468 | 55627 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | PB2125 | TERMINAL, RING (1) | 4 | ||||
| ? | EJ9257 | CABLE, REAR JUNCTION BOX | 1 | ||||
| ? | TG2568 | CLAMP - 7/8" I.D. | 2 | ||||
| ? | TG5720 | CAPSCREW - 3/8" - 16NC X 1" | 2 | ||||
| ? | TC1231 | LOCKWASHER - 3/8" | 2 | ||||
| ? | TR4436 | FLAT WASHER - 3/8" | 4 | ||||
| ? | VN9907 | CLAMP - 5/8" I.D. | 2 | ||||
| ? | C3145 | CAPSCREW - 1/4" - 20NC X 5/8" | 4 | ||||
| ? | DC3584 | LOCKWASHER - 1/4" | 4 | ||||
| ? | SP8417 | FLAT WASHER - 1/4" | 4 | ||||
| ? | EK7631 | JUNCTION BOX ASSEMBLY - REAR (SEE INDEX) | 1 | 55627 | |||
| ? | PC1578 | SENSOR, PRESSURE (1)/(2) | 2 | ||||
| ? | 07000-51009 | • O-RING | 2 | ||||
| ? | EH1251 | LOAD WEIGH VALVE ASSEMBLY | 2 | ||||
| ? | TZ8627 | • BODY, VALVE | 2 | ||||
| ? | TD7179 | • CORE, VALVE | 2 | ||||
| ? | 07000-51009 | • O-RING | 2 | ||||
| ? | AK4998 | NOTE: (1) INCLUDED IN AK4998 SENSOR KIT. | |||||
| ? | (2) NOT SERVICED SEPARATELY. ORDER AK4998 KIT. |
