| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | MM0602 | CAPSCREW - M8 X 1.25 X 80 | 4 | ||||
| ? | MM0470 | LOCKWASHER - M8 | 4 | ||||
| ? | MM0604 | CAPSCREW - M10 X 1.50 X 20 | 5 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 5 | ||||
| ? | MM0704 | FLAT WASHER - M10 (HARDENED) | 5 | ||||
| ? | EJ9089 | INTERFACE MODULE (IM) | 1 | ||||
| ? | WB2961 | NAME PLATE - AGND | 1 | ||||
| ? | WB3286 | STRIP, CIRCUIT ID | 2 | ||||
| ? | PC0618 | TERMINATING PLUG | 1 | ||||
| ? | PC0616 | TEE RECEPTACLE | 1 | ||||
| ? | 158400504 | NUT | 22 | ||||
| ? | VM2951 | SCREW, SELF-TAPPING - #6 - 32NC X 5/16" | 2 | ||||
| ? | WB3099 | STRIP, CIRCUIT 1D | 1 | ||||
| ? | PB5732 | TERMINAL BOARD | 1 | ||||
| ? | ED0913 | ROD, THREADED | 3 | ||||
| ? | TA7409 | INSULATOR, STAND OFF | 3 | ||||
| ? | CC6807 | LOCKWASHER - 1/4" (INTERNAL TOOTH) | 3 | ||||
| ? | VN9773 | FLAT WASHER - 1/4" | 3 | ||||
| ? | C5780 | NUT - 1/4" | 3 | ||||
| ? | EL0122 | HARNESS, VHMS | 1 | ||||
| ? | WB2960 | NAME PLATE - +18V | 1 | ||||
| ? | WB2959 | NAME PLATE - +5V | 1 | ||||
| ? | WB3170 | NAME PLATE - INTERFACE MODULE | 1 | ||||
| ? | EL0120 | PLATE, JUNCTION BOX | 1 |
