| Наименование | Страница | Код страницы |
|---|---|---|
| ELECTRONIC TREADLE (PB9506) | 182 | 41060 |
| ELECTRONIC TREADLE (PC1997) | 184 | 41958 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | MM0594 | CAPSCREW - M8 X 1.25 X 25 | 4 | ||||
| ? | MM0460 | FLAT WASHER - M8 | 4 | ||||
| ? | MM0470 | LOCKWASHER - M8 | 4 | ||||
| ? | SM1107 | BRACKET, TREADLE | 1 | ||||
| ? | DC4579 | MACHINE SCREW - #10 X 32NF X 5/8" | 2 | ||||
| ? | DC3101 | LOCKWASHER - #10 | 2 | ||||
| ? | TD1809 | CAPSCREW - 1/4" - 20NC X 3/4" | 2 | ||||
| ? | DC3584 | LOCKWASHER - 1/4" | 2 | ||||
| ? | TD1549 | NUT - 1/4" - 20NC | 2 | ||||
| ? | PC1997 | ELECTRIC TREADLE - RETARDER (SEE INDEX) | 1 | 41958 | |||
| ? | VC9049 | CAPSCREW - 5/16" - 18NC X 5/8" | 4 | ||||
| ? | SC4174 | LOCKWASHER - 5/16" | 4 | ||||
| ? | PB9506 | ELECTRIC TREADLE - THROTTLE (SEE INDEX) | 1 | 41060 | |||
| ? | TX6326 | PAD, FOOT | 1 | ||||
| ? | TX6335 | PEDAL, RETARDER | 1 | ||||
| ? | VN0137 | CLAMP, CUSHION - 7/16" | 1 |
