Номер на схеме	Каталожный номер	Название	Количество
?	XA2238	SEAT SUSPENSION ASSEMBLY	1
?		• FRAME, UPPER (1)	1
?	XA2247	• KIT, HARDWARE	1
?		• • ROLLER (1)	4
?		• • BOLT, SHOULDER (1)	2
?		• • WASHER, SPLITLOCK (1)	2
?		• • NUT, HEX (1)	2
?		• • BUSHING (1)	4
?		• • BUSHING (1)	2
?	BF0478	• • KIT, BUMPER	1
?		• • • BUMPER, UP (1)/(5)	2
?		• • • BUMPER, DOWN (1)	2
?		• • • WASHER, SPLITLOCK (1)	2
?		• • • NUT, HEX (1)	2
?	VE8721	• KIT, AIR COMPRESSOR	1
?		• • COMPRESSOR, AIR (1)/(2)	1
?	VE8744	• • ELBOW (2)	1
?	VE6664	• • CAP (2)	1
?	VE8874	• • CLAMP	4
?	VE8724	• KIT, AIR SPRING	1
?		• • SPRING, AIR (1)	1
?	VE8744	• • ELBOW	1
?	VE6664	• • CAP	1
?	VE8875	• • CAPSCREW (5)	2
?		• • WASHER (1)	2
?	BF0694	• KIT, SHOCK ABSORBER	1
?	BF0697	• • ABSORBER, SHOCK	1
?		• • CAPSCREW (1)	2
?		• • NUT (1)	2
?		• BUSHING (1)	2
?	BF0477	• KIT, AXLE	1
?		• • SHAFT, LOWER (1)	1
?		• • AXLE, UPPER (1)	1
?	VE4582	• • RING, SNAP	4
?	BF0091	• KIT, COMPRESSOR / RELAY	1
?		• • COMPRESSOR, AIR (1)/(3)	1
?	VE8744	• • ELBOW (3)	1
?	VE6664	• • CAP (3)	1
?		• • RELAY (1)	1
?	BF0503	• • HARNESS	1
?		• • CLAMP (1)	1
?		• • SCREW (1)	1
?		• FRAME, LOWER (1)	1
?		• SCISSOR, OUTER (1)	1
?		• SCISSOR, INNER (1)	1
?	BF0695	• KIT, BUMPER	1
?		• • BRACKET (1)	2
?		• • BUMPER, UP (1)/(6)	2
?	VE8875	• • CAPSCREW (4)	2
?		• • NUT, LOCK (1)	2
?		NOTE: (1) NOT SERVICED SEPARATELY.
?	BF0091	(2) ALSO INCLUDED IN BF0091 COMPRESSOR/RELAY KIT.
?	VE8721	(3) ALSO INCLUDED IN VE8721 AIR COMPRESSOR KIT.
?	VE8724	(4) ALSO INCLUDED IN VE8724 AIR SPRING KIT.
?	BF0695	(5) ALSO INCLUDED IN BF0695 BUMPER KIT.
?	BF0478	(6) ALSO INCLUDED IN BF0478 BUMPER KIT.

Dump Trucks Komatsu / AFE47-ED 730E S/N A30437 NITTETSU(AFE47-ED) / OPERATOR
