| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | WB1304 | CLAMP, CUSHION - 9/16" | 10 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 13 | ||||
| ? | MM0178 | NUT - M10 X 1.50 | 13 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 13 | ||||
| ? | WB3093 | CLAMP, CUSHION - 1" | 10 | ||||
| ? | WA1731 | O-RING - 5/16" | 3 | ||||
| ? | WA1733 | O-RING - 9/16" | 1 | ||||
| ? | HA8071 | HOSE | 1 | ||||
| ? | WB1027 | O-RING - 11/16" | 2 | ||||
| ? | PC1830 | ACCUMULATOR | 1 | ||||
| ? | 20D0911130 | CLAMP | 2 | ||||
| ? | PC1341 | BRACKET | 1 | ||||
| ? | MM0027 | CAPSCREW - M6 X 1.00 X 25 | 4 | ||||
| ? | MM0459 | FLAT WASHER - M6 | 4 | ||||
| ? | PB8689 | RECEIVER DRIER | 1 | ||||
| ? | HA7880 | HOSE | 1 | ||||
| ? | PB7619 | ADAPTER | 1 | ||||
| ? | PC1804 | SWITCH, TRINARY | 1 | ||||
| ? | HA7881 | HOSE | 1 | ||||
| ? | HA8070 | HOSE | 1 |
