Номер на схеме |
Каталожный номер |
Название |
Количество |
Детали |
|
|
|
? |
SM1094 |
GLASS, REAR |
1 |
|
|
|
|
? |
SM2045 |
CHANNEL, RUBBER |
1 |
|
|
|
|
? |
VE5837 |
LIGHT, DOME |
1 |
|
|
|
|
? |
VE8635 |
• LENS, PLASTIC |
1 |
|
|
|
|
? |
VE8636 |
• SWITCH |
1 |
|
|
|
|
? |
VZ1912 |
• BULB, 24 VOLT |
1 |
|
|
|
|
? |
SM2879 |
GLASS, FRONT - R.H. |
1 |
|
|
|
|
? |
SM5949 |
DOOR ASSEMBLY - R.H. (SEE FIG 60554) |
1 |
|
60554 |
|
|
? |
PC0841 |
• WINDOW ASSEMBLY |
1 |
|
|
|
|
? |
SM2265 |
• • GLASS |
1 |
|
|
|
|
? |
SM2839 |
PLATE, CONNECTOR (SEE FIG 60663) |
1 |
|
60663 |
|
|
? |
MM0027 |
CAPSCREW - M6 X 1.00 X 25 |
8 |
|
|
|
|
? |
MM0469 |
LOCKWASHER - M6 |
8 |
|
|
|
|
? |
SM4419 |
PLATE, ACCESS - R.H. FLOOR |
1 |
|
|
|
|
? |
MM0606 |
CAPSCREW - M10 X 1.50 X 30 |
12 |
|
|
|
|
? |
MM0471 |
LOCKWASHER - M10 |
12 |
|
|
|
|
? |
SM2189 |
PLATE, ACCESS - L.H. FLOOR |
1 |
|
|
|
|
? |
SM0991 |
PLATE, FRONT ACCESS - BRAKE & STEERING PIPING |
1 |
|
|
|
|
? |
SM0992 |
PLATE, REAR ACCESS - BRAKE & STEERING PIPING |
1 |
|
|
|
|
? |
31154R1 |
CAPSCREW - M8 X 12 |
14 |
|
|
|
|
? |
SM2402 |
SEAL, DOOR |
1 |
|
|
|
|
? |
SM2167 |
STRAP, DOOR CHECK |
2 |
|
|
|
|
? |
SM2165 |
BRACKET, DOOR STRAP |
2 |
|
|
|
|
? |
SM2168 |
CAPSCREW, DRILLED |
4 |
|
|
|
|
? |
SM2322 |
CLIP, HAIR PIN |
4 |
|
|
|
|
? |
SM2582 |
SEAL, INNER DOOR |
2 |
|
|
|
|
? |
MM0470 |
LOCKWASHER - M8 |
14 |
|
|
|
|
? |
MM0595 |
CAPSCREW - M8 X 1.25 X 30 |
14 |
|
|
|
|
? |
MM0074 |
CAPSCREW - M24 X 3.00 X 70 |
32 |
|
|
|
|
? |
EC7592 |
FLAT WASHER - M24 (HARDENED) |
32 |
|
|
|
|
? |
|
NOTE: NS = NOT SHOWN |
|
|
|
|
|
? |
PB2849 |
EXTINGUISHER, FIRE (1) |
1 |
|
|
|
|
? |
PB2850 |
BRACKET, FENDER (1) |
1 |
|
|
|
|
? |
H8524 |
CAPSCREW - 3/8" - 16NC X 5/8" (1) |
3 |
|
|
|
|
? |
C0312 |
LOCKWASHER - 3/8" (1) |
3 |
|
|
|
|
? |
|
NOTE: (1) OPTIONAL EQUIPMENT. |
|
|
|
|
