Номер на схеме |
Каталожный номер |
Название |
Количество |
Детали |
|
|
|
? |
HA6502 |
HOSE |
3 |
|
|
|
|
? |
WB0508 |
FITTING - 90 DEG |
3 |
|
|
|
|
? |
TF8090 |
CLAMP, SPLIT FLANGE |
2 |
|
|
|
|
? |
VG9095 |
O-RING |
1 |
|
|
|
|
? |
C1614 |
CAPSCREW - 1/2" - 13NC X 1 1/2" |
12 |
|
|
|
|
? |
C1540 |
LOCKWASHER - 1/2" |
12 |
|
|
|
|
? |
TD0791 |
CAPSCREW - 3/8" - 16NC X 1 1/4" |
6 |
|
|
|
|
? |
TC1231 |
LOCKWASHER - 3/8" |
12 |
|
|
|
|
? |
VN9037 |
CAPSCREW - 3/8" - 16NC X 1 1/4" |
8 |
|
|
|
|
? |
C0312 |
LOCKWASHER - 3/8" |
17 |
|
|
|
|
? |
WA0386 |
NUT - 3/8" - 16NC |
8 |
|
|
|
|
? |
EG9343 |
COVER, TOP |
1 |
|
|
|
|
? |
EG9344 |
COVER, BOTTOM |
1 |
|
|
|
|
? |
PC0184 |
DRIVE SHAFT ASSEMBLY (SEE FIG 55350) |
1 |
|
55350 |
|
|
? |
SG7814 |
CAPSCREW - 3/8" - 24NF X 1 1/4" |
8 |
|
|
|
|
? |
TL7218 |
CAPSCREW - 3/8" - 16NC X 7/8" |
6 |
|
|
|
|
? |
TF3231 |
CLAMP, SPLIT FLANGE |
4 |
|
|
|
|
? |
WA0187 |
O-RING |
2 |
|
|
|
|
? |
HA7768 |
HOSE |
1 |
|
|
|
|
? |
HA7695 |
HOSE |
1 |
|
|
|
|
? |
HA4273 |
HOSE |
1 |
|
|
|
|
? |
HA7770 |
HOSE |
1 |
|
|
|
|
? |
HA2463 |
HOSE |
2 |
|
|
|
|
? |
HA7431 |
HOSE |
2 |
|
|
|
|
? |
HA7723 |
HOSE |
1 |
|
|
|
|
? |
VL9963 |
CLAMP, SPLIT FLANGE |
4 |
|
|
|
|
? |
WA0237 |
O-RING |
3 |
|
|
|
|
? |
C1629 |
CAPSCREW - 5/8" - 11NC X 1 3/4" |
4 |
|
|
|
|
? |
C1541 |
LOCKWASHER - 5/8" |
8 |
|
|
|
|
? |
HA7340 |
HOSE |
1 |
|
|
|
|
? |
VM0313 |
PLUG |
2 |
|
|
|
|
? |
EG0479 |
FLANGE, ADAPTOR |
1 |
|
|
|
|
? |
WA0232 |
O-RING |
2 |
|
|
|
|
? |
VH6718 |
CLAMP, SPLIT FLANGE |
2 |
|
|
|
|
? |
C1619 |
CAPSCREW - 1/2" - 13NC X 2 3/4" |
4 |
|
|
|
|
? |
TF3237 |
CLAMP |
2 |
|
|
|
|
? |
VG9096 |
O-RING |
2 |
|
|
|
|
? |
C1609 |
CAPSCREW - 7/16" - 14NC X 1 1/2" |
4 |
|
|
|
|
? |
C5775 |
LOCKWASHER - 7/16" |
4 |
|
|
|
|
? |
TF6925 |
CLAMP |
1 |
|
|
|
|
? |
VH9969 |
STUD, WELD - 3/8" - 16NC X 3/4" |
1 |
|
|
|
|
? |
C1521 |
NUT - 3/8" - 16NC |
1 |
|
|
|
|
? |
EF8352 |
ADAPTOR, FLANGE |
1 |
|
|
|
|
? |
C1634 |
CAPSCREW - 5/8" - 11NC X 3" |
4 |
|
|
|
|
? |
HA5194 |
HOSE |
1 |
|
|
|
