| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | EK4376 | DUCT, INLET | 1 | ||||
| ? | TR1376 | CAPSCREW - 1/2" - 13NC X 1 1/4" | 4 | ||||
| ? | TR6008 | FLAT WASHER - 1/2" | 10 | ||||
| ? | MM0110 | CAPSCREW - M16 X 2.00 X 100 | 4 | ||||
| ? | MM0706 | FLAT WASHER - M16 | 12 | ||||
| ? | MM0474 | LOCKWASHER - M16 | 12 | ||||
| ? | MM0080 | CAPSCREW - M16 X 2.OO X 50 | 2 | ||||
| ? | MM0181 | NUT - M16 X 2.00 | 2 | ||||
| ? | EK2836 | DECK, CENTER | 1 | ||||
| ? | EG2812 | SUPPORT | 1 | ||||
| ? | MM0125 | CAPSCREW - M16 X 2.00 X 120 | 4 | ||||
| ? | TW6954 | U-CLAMP | 6 | ||||
| ? | MM0042 | CAPSCREW - M10 X 1.50 X 25 | 12 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 22 | ||||
| ? | MM0178 | NUT - M10 X 1.50 | 22 | ||||
| ? | MM0050 | CAPSCREW - M10 X 1.50 X 35 | 10 | ||||
| ? | TK1427 | GASKET | 1 | ||||
| ? | EB8014 | TRANSITION | 1 | ||||
| ? | TY3656 | BAR | 4 | ||||
| ? | WA4497 | SCREW, SELF TAPPING (SPECIAL) | 32 | ||||
| ? | TY3655 | BOOT | 1 | ||||
| ? | JG9620 | BAR | 4 | ||||
| ? | MM0053 | CAPSCREW - M12 X 1.75 X 45 | 4 | ||||
| ? | MM0472 | LOCKWASHER - M12 | 4 | ||||
| ? | EC7593 | FLAT WASHER | 16 | ||||
| ? | EB9388 | DECK, REAR CENTER CATWALK | 1 | ||||
| ? | MM0694 | LOCKNUT - M12 X 1.75 | 4 | ||||
| ? | EB9747 | PLATE, BENT - R.H. | 1 | ||||
| ? | EB9748 | PLATE, BENT - L.H. | 1 | ||||
| ? | EB4426 | HOSE, AIR | 1 | ||||
| ? | WA1060 | CLAMP, T-BOLT | 2 | ||||
| ? | NOTE: NS = NOT SHOWN | ||||||
| ? | PB7081 | SWITCH, PRESSURE | 1 |
