| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | PB9923 | MOTOR, WIPER - 24 VOLT | 1 | ||||
| ? | MM0592 | CAPSCREW - M8 X 1.25 X 16 | 5 | ||||
| ? | MM0712 | FLAT WASHER - M8 (HARDENED) | 9 | ||||
| ? | MM0470 | LOCKWASHER - M8 | 5 | ||||
| ? | SM4345 | PLATE | 1 | ||||
| ? | MM0581 | CAPSCREW - M6 X 1.00 X 16 | 3 | ||||
| ? | MM0711 | FLAT WASHER - M6 (HARDENED) | 3 | ||||
| ? | MM0469 | LOCKWASHER - M6 | 3 | ||||
| ? | PB9926 | WIPER LINKAGE ASSEMBLY | 1 | ||||
| ? | PB9924 | ARM, WET WIPER | 2 | ||||
| ? | XA2095 | NOZZLE | 2 | ||||
| ? | PB9925 | BLADE, WIPER | 2 | ||||
| ? | MM0022 | CAPSCREW - M8 X 1.25 X 20 | 4 | ||||
| ? | MM0460 | FLAT WASHER - M8 | 4 | ||||
| ? | EG0735 | TEE, HOSE | 1 | ||||
| ? | TF6380 | GROMMET, RUBBER | 2 | ||||
| ? | SM4477 | HOSE | 2 | ||||
| ? | EC8892 | HOSE | 2 | ||||
| ? | PB7514 | WINDSHIELD WASHER ASSEMBLY | 1 | ||||
| ? | VE2942 | • CAP | 1 | ||||
| ? | VE2941 | • PUMP | 1 | ||||
| ? | VE6598 | • GROMMET | 1 | ||||
| ? | VE5339 | • TANK - 4 QT. | 1 | ||||
| ? | TD1548 | CAPSCREW - 1/4" - 20NC X 5/8" | 4 | ||||
| ? | DC3584 | LOCKWASHER - 1/4" | 4 | ||||
| ? | TD1549 | NUT - 1/4" - 20NC | 4 |
