| Наименование | Страница | Код страницы |
|---|---|---|
| STEERING CONTROL UNIT (PB6905) | 098 | 14608 |
| STEERING COLUMN ASSEMBLY (PC1287) | 096 | 41730 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | PC0683 | WHEEL, STEERING | 1 | ||||
| ? | PB6846 | BUTTON, HORN | 1 | ||||
| ? | EJ9890 | STEERING COLUMN ASSEMBLY | 1 | ||||
| ? | PC1287 | • COLUMN, STEERING (SEE INDEX) | 1 | 41730 | |||
| ? | MM0350 | • SCREW, MACHINE - M5 X .8 X 16 (PAN HD) | 2 | ||||
| ? | MM0379 | • LOCKWASHER - M5 (EXT TOOTH) | 2 | ||||
| ? | SM5866 | • TURN SIGNAL ASSEMBLY | 1 | ||||
| ? | PC0755 | • • SIGNAL, TURN | 1 | ||||
| ? | DL8434 | • • RING, TERMINAL | 1 | ||||
| ? | VH5019 | • • CONNECTOR, PIN | 8 | ||||
| ? | VL0954 | • • HOUSING, PIN | 1 | ||||
| ? | MM0604 | CAPSCREW - M10 X 1.50 X 20 | 8 | ||||
| ? | MM0713 | FLAT WASHER - M10 | 16 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 8 | ||||
| ? | VC8762 | CAPSCREW - 3/8" - 16NC X 1 1/2" | 4 | ||||
| ? | TC1231 | LOCKWASHER - 3/8" | 4 | ||||
| ? | EJ9842 | BRACKET - R.H. | 1 | ||||
| ? | EJ9843 | BRACKET - L.H. | 1 | ||||
| ? | TC1233 | NUT - 3/8" - 16NC | 4 | ||||
| ? | PB6905 | VALVE, STEERING CONTROL (SEE INDEX) | 1 | 14608 |
