| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | HA7514 | HOSE | 1 | ||||
| ? | WB0588 | ADAPTOR, STRAIGHT | 1 | ||||
| ? | WB0376 | FITTING - 90 DEG | 1 | ||||
| ? | WB0561 | FITTING, TEE | 2 | ||||
| ? | WB0364 | FITTING, STRAIGHT ADAPTOR | 2 | ||||
| ? | TV5648 | HOSE - TO MANIFOLD HEAT EXCHANGER | 1 | ||||
| ? | HA7464 | HOSE | 2 | ||||
| ? | PB9921 | VALVE, CHECK | 1 | ||||
| ? | EG2630 | PLATE, BENT | 2 | ||||
| ? | HA2802 | HOSE - FROM FILTER TOP PORT | 1 | ||||
| ? | C8558 | CAPSCREW - 3/8" - 16NC X 3 1/4" | 1 | ||||
| ? | TR4436 | FLAT WASHER - 3/8" | 1 | ||||
| ? | C0312 | LOCKWASHER - 3/8" | 1 | ||||
| ? | C1521 | NUT - 3/8" - 16NC | 1 | ||||
| ? | C5769 | PLUG, PIPE | 1 | ||||
| ? | WB0523 | FITTING - 90 DEG | 2 | ||||
| ? | TR9441 | CLAMP | 5 | ||||
| ? | C1615 | CAPSCREW - 1/2" - 13NC X 1 3/4" | 1 | ||||
| ? | C1540 | LOCKWASHER - 1/2" | 6 | ||||
| ? | C1523 | NUT - 1/2" - 13NC | 7 | ||||
| ? | E7656 | CAPSCREW - 1/2" - 13NC X 1/2" | 5 | ||||
| ? | TG2563 | CLAMP | 2 |
