| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | PB6489 | PANEL | 1 | ||||
| ? | VE5003 | MOULDED BOX | 1 | ||||
| ? | VE5004 | COVER ASSEMBLY | 1 | ||||
| ? | VE5005 | GASKET - 10.76" | 2 | ||||
| ? | VE5006 | GASKET - 17.50" | 2 | ||||
| ? | VE3035 | CEMENT | |||||
| ? | VE5007 | BUS BAR ASSEMBLY | 2 | ||||
| ? | VE5008 | BUS BAR | 4 | ||||
| ? | VE5033 | BUS BAR, INSULATED - 15.86" DEVELOPED LENGTH | 1 | ||||
| ? | VE5034 | BUS BAR, INSULATED - 21.47" DEVELOPED LENGTH | 1 | ||||
| ? | VE5011 | BUS BAR ASSEMBLY | 1 | ||||
| ? | VE4326 | HEAT SINK | 6 | ||||
| ? | VE4651 | LOCKWASHER - 1/4" | 8 | ||||
| ? | VE4840 | CAPSCREW - 1/4" - 20NC X 1.125" | 4 | ||||
| ? | VE4640 | CAPSCREW - 3/8" - 16NC X 1 1/2" | 4 | ||||
| ? | VE4515 | FLAT WASHER | 18 | ||||
| ? | VE4687 | LOCKWASHER - 3/8" | 12 | ||||
| ? | TC1233 | NUT - 3/8" - 16NC | 10 | ||||
| ? | VE4639 | CAPSCREW - 3/8" - 16NC X 1" | 2 | ||||
| ? | VE4697 | CAPSCREW - 5/16" - 18NC X 2" | 24 | ||||
| ? | VE4343 | FLAT WASHER | 44 | ||||
| ? | VE4687 | LOCKWASHER - 3/8" | 44 | ||||
| ? | VE5013 | NUT - 5/16" - 18NC | 44 | ||||
| ? | VE5014 | BUS BAR | 6 | ||||
| ? | VE5015 | BUS BAR | 4 | ||||
| ? | VE5016 | CAPSCREW - 5/16" - 18NC | 20 | ||||
| ? | VE5017 | SEALER (RTV 106) | |||||
| ? | VE5018 | SPACER - 1" X 1/4" | 20 | ||||
| ? | VE5019 | SPACER - 3 5/16" | 4 | ||||
| ? | VE5020 | SPACER - 3 7/8" | 4 | ||||
| ? | VE5021 | SPACER - 4 1/8" | 4 | ||||
| ? | VE5041 | BUS BAR, L-SHAPED, INSULATED - 8.07" DEVELOPED LENGTH | 3 | ||||
| ? | VE5023 | HANDLE | 2 | ||||
| ? | VE5024 | MACHINE SCREW - 1/4" X 1" | 4 | ||||
| ? | DF3445 | FLAT WASHER - 1/4" | 8 |
