| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VE1474 | CAP, RADIATOR - 14PSI | 1 | ||||
| ? | BF4510 | TANK, SURGE | 1 | ||||
| ? | VE4014 | PLUG - 3/8" NPT | 1 | ||||
| ? | VE4013 | FITTING | 4 | ||||
| ? | VE4011 | FITTING | 4 | ||||
| ? | VE4443 | HOSE | 2 | ||||
| ? | C1602 | CAPSCREW - 3/8" - 16NC X 1" | 24 | ||||
| ? | E3735 | FLAT WASHER - 3/8" | 54 | ||||
| ? | C0312 | LOCKWASHER - 3/8" | 64 | ||||
| ? | C1521 | NUT - 3/8" - 16NC | 48 | ||||
| ? | BF2443 | BAFFLE | 2 | ||||
| ? | VE3460 | CAPSCREW | 44 | ||||
| ? | VE4440 | WASHER | 4 | ||||
| ? | VE4005 | CAPSCREW - 3/8" - 16NC X 3/4" | 22 | ||||
| ? | VE4447 | NIPPLE | 1 | ||||
| ? | VE4446 | REDUCER | 1 | ||||
| ? | VE4441 | ELBOW | 1 | ||||
| ? | C5769 | PLUG, PIPE | 1 | ||||
| ? | VE1954 | BRACKET, X-BRACE | 2 | ||||
| ? | C5747 | CAPSCREW - 5/16" - 18NC X 3/4" | 4 | ||||
| ? | VE5442 | FLAT WASHER | 8 | ||||
| ? | VE6312 | NUT | 4 | ||||
| ? | VE4450 | NIPPLE | 2 | ||||
| ? | VE4000 | GROMMET, RUBBER | 1002 | ||||
| ? | BF2445 | AIR BAFFLE, BOTTOM | 4 | ||||
| ? | VE7899 | HOSE, OVERFLOW | 1 | ||||
| ? | VE1223 | CLIP | 3 | ||||
| ? | C1526 | NUT - 5/8" - 11NC | 12 | ||||
| ? | VE7898 | ROD, X-BRACE | 2 | ||||
| ? | VE3999 | GROMMET, RUBBER | 1002 | ||||
| ? | VE9736 | TUBE ASSEMBLY | 536 | ||||
| ? | VE1095 | TUBE | 466 | ||||
| ? | VE1219 | TUBE STAY END | 24 | ||||
| ? | BF2444 | AIR BAFFLE, TOP | 4 | ||||
| ? | PB6680 | GAUGE, SIGHT | 1 | ||||
| ? | VE4442 | HOSE | 2 | ||||
| ? | VE4012 | FITTING | 4 | ||||
| ? | VE4010 | FITTING | 4 | ||||
| ? | BF2440 | TANK | 1 | ||||
| ? | BF2804 | TANK | 1 | ||||
| ? | C1603 | CAPSCREW - 3/8" - 16NC X 1 1/4" | 24 | ||||
| ? | VE3995 | SUPPORT, CENTER | 2 | ||||
| ? | BF5012 | TANK, CENTER | 1 | ||||
| ? | VE7894 | SIDE MEMBER - R.H. | 1 | ||||
| ? | VE7895 | SIDE MEMBER - L.H. | 1 | ||||
| ? | VE7892 | SIDE MEMBER - R.H. | 1 | ||||
| ? | VE7893 | SIDE MEMBER - L.H. | 1 | ||||
| ? | BF5011 | TANK | 1 | ||||
| ? | BF2652 | TANK | 1 | ||||
| ? | VE7891 | TANK, CENTER | 1 | ||||
| ? | VE3998 | SUPPORT, CENTER | 2 | ||||
| ? | VE7896 | RING, FAN | 1 | ||||
| ? | BF2442 | SHROUD, FAN | 1 | ||||
| ? | VE4449 | ELBOW, STREET | 1 | ||||
| ? | VE4451 | VALVE, SWING | 1 | ||||
| ? | VE7257 | HOSE | 1 | ||||
| ? | VE4452 | CLAMP, HOSE | 2 | ||||
| ? | VE4448 | TEE | 1 | ||||
| ? | H6881 | PLUG - 1" NPT | 1 | ||||
| ? | VE4990 | PIPE | 2 | ||||
| ? | C1540 | LOCKWASHER - 1/2" | 40 | ||||
| ? | BF3694 | BUSHING, REDUCING | 2 | ||||
| ? | BF3695 | COUPLING, PIPE | 1 | ||||
| ? | BF3696 | BRACKET | 1 | ||||
| ? | BF3697 | VALVE | 1 | ||||
| ? | VE4009 | HOSE | 1 | ||||
| ? | BF3693 | ELBOW - 90 DEG | 1 |
