| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | EH5940 | STEERING CYLINDER ASSEMBLY | 1 | ||||
| ? | VL7694 | • LOCKWASHER - 1 3/4" - 12NC (NYLON) | 1 | ||||
| ? | VN5604 | • BEARING | 1 | ||||
| ? | PC0586 | • SEAL, PISTON | 1 | ||||
| ? | EH5942 | • PISTON | 1 | ||||
| ? | EH5943 | • HOUSING, CYLINDER | 1 | ||||
| ? | TG0094 | • SEAL, O-RING | 1 | ||||
| ? | WA1429 | • RING, BACKUP | 1 | ||||
| ? | EF7976 | • GLAND | 1 | ||||
| ? | EH5945 | • ROD | 1 | ||||
| ? | PB9678 | • BEARING - 2 1/2" | 1 | ||||
| ? | PC0587 | • SEAL, ROD - 2 1/2" | 1 | ||||
| ? | PB9691 | • WIPER, ROD - 2 1/2" | 1 | ||||
| ? | • (NOT USED THIS APPLICATION) | ||||||
| ? | TD8516 | • CAPSCREW - 3/4" - 10NC X 3 1/4" | 2 | ||||
| ? | TD7882 | • CAPSCREW - 3/4" - 10NC X 1 3/4" | 4 | ||||
| ? | H8524 | • CAPSCREW - 3/8" - 16NC X 5/8" (1) | 8 | ||||
| ? | WA2701 | • COVER, FLANGE HEAD (1) | 2 | ||||
| ? | PC0830 | BEARING, SPHERICAL (2) | 2 | ||||
| ? | EB4427 | RETAINER, BEARING | 2 | ||||
| ? | C1602 | CAPSCREW - 3/8" - 16NC X 1" | 12 | ||||
| ? | C0312 | LOCKWASHER - 3/8" | 12 | ||||
| ? | NOTE: (1) USED FOR SHIPPING PURPOSES ONLY. | ||||||
| ? | AK3732 | (2) INCLUDED IN AK3732 STEERING CYLINDER & TIE ROD PIN KIT. | |||||
| ? | (QUANTITIES SHOWN ARE FOR ONE SIDE ONLY.) |
