Номер на схеме |
Каталожный номер |
Название |
Количество |
Детали |
|
|
|
? |
PB8838 |
STATIC EXCITER PANEL, ALTERNATOR FIELD (SEE INDEX) |
1 |
|
64071A |
|
|
? |
ED6878 |
GASKET |
1 |
|
|
|
|
? |
MM0460 |
FLAT WASHER - M8 |
12 |
|
|
|
|
? |
MM0470 |
LOCKWASHER - M8 |
12 |
|
|
|
|
? |
MM0177 |
NUT - M8 |
12 |
|
|
|
|
? |
PB8837 |
STATIC EXCITER PANEL, MOTOR FIELD (SEE INDEX) |
1 |
|
64073 |
|
|
? |
PB4262 |
TRANSFORMER, CURRENT |
1 |
|
|
|
|
? |
MM0046 |
CAPSCREW - M6 X 1.00 X 40 |
2 |
|
|
|
|
? |
MM0469 |
LOCKWASHER - M6 |
6 |
|
|
|
|
? |
ED0369 |
PLATE, NAME - 71K |
1 |
|
|
|
|
? |
ED0370 |
PLATE, NAME - 7J13 |
1 |
|
|
|
|
? |
ED0360 |
PLATE, NAME - 75X |
1 |
|
|
|
|
? |
ED0372 |
PLATE, NAME - 74E |
1 |
|
|
|
|
? |
ED0359 |
PLATE, NAME - 74AA |
1 |
|
|
|
|
? |
ED0358 |
PLATE, NAME - 71J |
2 |
|
|
|
|
? |
TZ7513 |
PLATE, NAME - AFSE |
1 |
|
|
|
|
? |
ED0368 |
PLATE, NAME - 7J14 |
1 |
|
|
|
|
? |
EC7468 |
PLATE, NAME - 7J1LS |
1 |
|
|
|
|
? |
EC7467 |
PLATE, NAME - 7J8 |
1 |
|
|
|
|
? |
ED0374 |
PLATE, NAME - 74F |
1 |
|
|
|
|
? |
EC7466 |
PLATE, NAME - 7J1L |
1 |
|
|
|
|
? |
EC7465 |
PLATE, NAME - 7J1R |
1 |
|
|
|
|
? |
EC7464 |
PLATE, NAME - 7J7 |
1 |
|
|
|
|
? |
EC7469 |
PLATE, NAME - 7J1RS |
1 |
|
|
|
|
? |
EC2026 |
HOUSING |
1 |
|
|
|
|
? |
TK7659 |
RESISTOR |
1 |
|
|
|
|
? |
EC7257 |
PLATE, NAME - CTR |
1 |
|
|
|
|
? |
TZ7516 |
PLATE, NAME - CT |
1 |
|
|
|
|
? |
TZ7514 |
PLATE, NAME - MFSE |
1 |
|
|
|
|
? |
ED0361 |
PLATE, NAME - 71G |
1 |
|
|
|
|
? |
ED0362 |
PLATE, NAME - 74D |
1 |
|
|
|
|
? |
ED0363 |
PLATE, NAME - 7J9 |
1 |
|
|
|
|
? |
SR8325 |
SWITCH, TOGGLE |
2 |
|
|
|
|
? |
VF6697 |
LIGHT INDICATOR |
1 |
|
|
|
|
? |
VL6234 |
• LAMP, MINIATURE |
1 |
|
|
|
|
? |
WB2078 |
DECAL, SWITCH |
1 |
|
|
|
|
? |
PB8056 |
PANEL, DISPLAY EVENT (SEE INDEX) |
1 |
|
64147 |
|
|
? |
MM0176 |
NUT - M6 |
4 |
|
|
|
|
? |
MM0459 |
FLAT WASHER - M6 |
4 |
|
|
|
|
? |
ED3404 |
BRACKET |
1 |
|
|
|
