| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | AK8072 | BASE, RIM - 57" X 27" | 1 | ||||
| ? | AK8010 | BAND, BEAD SEAT - 57" | 1 | ||||
| ? | PB6512 | O-RING | 1 | ||||
| ? | AK7741 | RING, SIDE | 2 | ||||
| ? | AK8014 | RING, LOCK - 57" | 1 | ||||
| ? | PB2612 | SPUD, COLLIE | 1 | ||||
| ? | VS5592 | STEM - 90 DEG SWIVEL | 1 | ||||
| ? | TX5766 | TUBE | 1 | ||||
| ? | VJ8012 | HOUSING, CORE | 1 | ||||
| ? | WA2670 | CAP, VALVE | 1 | ||||
| ? | S5716 | CAPSCREW - 1/4" - 20NC X 7/8" | 1 | ||||
| ? | VN9773 | FLAT WASHER - 1/4" | 1 | ||||
| ? | C5774 | LOCKWASHER - 1/4" | 1 | ||||
| ? | EC6139 | LUG, WHEEL | 35 | ||||
| ? | DC7524 | CAPSCREW - 3/8" - 16NC X 7/8" | 1 | ||||
| ? | C1547 | FLAT WASHER - 3/8" | 1 | ||||
| ? | C0312 | LOCKWASHER - 3/8" | 1 | ||||
| ? | C1521 | NUT - 3/8" - 16NC | 1 | ||||
| ? | WA4649 | CLAMP | 1 | ||||
| ? | TA2572 | NUT - 1" - 14UNS | 35 | ||||
| ? | TY1633 | STUD - 1" - 14UNS X 7 1/4" (SEE SPINDLE, HUB & BRAKE PG) | 35 | ||||
| ? | TY1256 | PLATE, BENT | 1 | ||||
| ? | (QUANTITIES SHOWN ARE FOR ONE SIDE ONLY.) |
