| Наименование | Страница | Код страницы |
|---|---|---|
| HOIST CYLINDER ASSM EJ5971 (2) (EJ9931 (3)) | 336 | 55043 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | EC6820 | PIN, UPPER HOIST (1) | 1 | ||||
| ? | PC0831 | BUSHING, BALL (1) | 1 | ||||
| ? | PB9934 | RING, RETAINER (INTERNAL) (1) | 2 | ||||
| ? | MM0155 | CAPSCREW - M36 X 4.00 X 220 (1) | 1 | ||||
| ? | MM0700 | LOCKNUT - M36 X 4.00 (1) | 1 | ||||
| ? | EJ5971 | HOIST CYLINDER ASSEMBLY (SEE FIG 55043) (2) | 1 | 55043 | |||
| ? | EJ9931 | HOIST CYLINDER ASSEMBLY (SEE FIG 55043) (3) | 1 | 55043 | |||
| ? | JG9884 | SHAFT, HOIST BEARING | 1 | ||||
| ? | VN9351 | RING, RETAINER | 2 | ||||
| ? | VA4707 | PLATE, RETAINER | 1 | ||||
| ? | TX3664 | PLATE, LOCKING | 1 | ||||
| ? | C7645 | CAPSCREW - 3/4" - 10NC X 1 1/2" | 4 | ||||
| ? | PB9622 | BUSHING, BALL | 1 | ||||
| ? | VA5501 | SPACER, BEARING | 1 | ||||
| ? | AK3734 | NOTE: (1) INCLUDED IN AK3734 UPPER HOIST PIN KIT. | |||||
| ? | (2) EFFECTIVE WITH A30188 ONLY. | ||||||
| ? | (3) EFFECTIVE WITH A30204 & A30209 ONLY. | ||||||
| ? | (QUANTITIES SHOWN ARE FOR ONE SIDE ONLY.) |
