| Наименование | Страница | Код страницы |
|---|---|---|
| JUNCTION BOX ASSEMBLY - L.H. (EK1722) | 364 | 60638 |
| JUNCTION BOX ASSEMBLY - R.H. (EK1723) | 366 | 60639 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | TC6058 | CLAMP - 1 1/2" I.D. | 21 | ||||
| ? | TG5720 | CAPSCREW - 3/8" - 16NC X 1" | 13 | ||||
| ? | TC1231 | LOCKWASHER - 3/8" | 13 | ||||
| ? | EJ9255 | HARNESS - PLM III JUNCTION BOX / TCI | 1 | ||||
| ? | TG2568 | CLAMP - 7/8" I.D. | 16 | ||||
| ? | MM0605 | CAPSCREW - M10 X 1.50 X 25 | 21 | ||||
| ? | MM0461 | FLAT WASHER - M10 | 41 | ||||
| ? | EJ9257 | CABLE, REAR JUNCTION BOX | 1 | ||||
| ? | 424243 | CLAMP - 3/8" ID | 35 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 25 | ||||
| ? | VH2584 | TERMINAL, RING | 4 | ||||
| ? | EK1722 | JUNCTION BOX ASSM - L.H. (SEE INDEX) | 1 | 60638 | |||
| ? | SP8417 | FLAT WASHER - 1/4" | 8 | ||||
| ? | DC3584 | LOCKWASHER - 1/4" | 8 | ||||
| ? | C3145 | CAPSCREW - 1/4" - 20NC X 5/8" | 8 | ||||
| ? | EH2342 | CABLE | 1 | ||||
| ? | EK1723 | JUNCTION BOX ASSM - R.H. (SEE INDEX) | 1 | 60639 | |||
| ? | EJ9258 | CABLE | 1 | ||||
| ? | EJ9638 | SLEEVING, HOSE | 2 | ||||
| ? | EH1251 | LOAD WEIGH VALVE ASSEMBLY | 2 | ||||
| ? | TZ8627 | • BODY, VALVE | 2 | ||||
| ? | TD7179 | • CORE, VALVE | 2 | ||||
| ? | 07000-51009 | • O-RING | 2 | ||||
| ? | PC0328 | SENSOR, PRESSURE | 2 |
