| Наименование | Страница | Код страницы |
|---|---|---|
| LIGHT ASSEMBLY (SUPER HALOGEN) - 2 | 286 | 40869 |
| LIGHT ASSEMBLY (SUPER HALOGEN) - 2 | 286 | 40869 |
| LIGHT ASSEMBLY (SUPER HALOGEN) - 2 | 286 | 40869 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | AK3359 | TAIL & STOP LIGHT ASSM (SEE FIG 40869) | 2 | 40869 | |||
| ? | SP8708 | LOCKWASHER - 3/8" | 6 | ||||
| ? | AK3357 | TURN/CLEARANCE LIGHT ASSEMBLY (SEE FIG 40869) | 2 | 40869 | |||
| ? | AK3320 | BACKUP LIGHT ASSEMBLY (SEE FIG 40869) | 2 | 40869 | |||
| ? | 424243 | CLAMP | 1 | ||||
| ? | MM0471 | LOCKWASHER - M10 | 5 | ||||
| ? | MM0178 | NUT - M10 X 1.50 | 5 | ||||
| ? | TG2562 | CLAMP | 1 | ||||
| ? | 720462 | CLAMP | 2 | ||||
| ? | 736131C2 | HORN, BACKUP | 2 | ||||
| ? | C5753 | CAPSCREW - 3/8" - 16NC X 4" | 4 | ||||
| ? | TC1231 | LOCKWASHER - 3/8" | 4 | ||||
| ? | TC1233 | NUT - 3/8" - 16NC | 4 | ||||
| ? | EJ5523 | HARNESS - REAR LIGHTS & BACKUP HORN | 1 | ||||
| ? | VN9907 | CLAMP | 1 | ||||
| ? | VZ3028 | GRIP, CORD | 1 |
