Номер на схеме |
Каталожный номер |
Название |
Количество |
Детали |
|
|
|
? |
ED8926 |
• ACCUMULATOR ASSEMBLY (SEE INDEX) |
2 |
|
|
|
|
? |
EC3038 |
• • CLAMP, UPPER MOUNTING |
1 |
|
|
|
|
? |
EC3036 |
• • CLAMP, HALF |
4 |
|
|
|
|
? |
MM0086 |
• • CAPSCREW - M16 X 2.00 X 60 |
8 |
|
|
|
|
? |
MM0706 |
• • FLAT WASHER (HARDENED) - M16 |
16 |
|
|
|
|
? |
MM0474 |
• • LOCKWASHER - M16 |
8 |
|
|
|
|
? |
MM0181 |
• • NUT - M16 X 2.00 |
8 |
|
|
|
|
? |
EC3040 |
• • CLAMP, LOWER MOUNTING |
1 |
|
|
|
|
? |
TN6999 |
• • COVER |
2 |
|
|
|
|
? |
PB8333 |
• • SWITCH, PRESSURE |
2 |
|
|
|
|
? |
EC1015 |
• • LOAD WEIGHING VALVE ASSEMBLY (1)/(2) |
2 |
|
|
|
|
? |
EC1447 |
• • BODY, VALVE (2) |
2 |
|
|
|
|
? |
TD7179 |
• • CORE, VALVE (2) |
2 |
|
|
|
|
? |
TL3995 |
• • O-RING (2) |
2 |
|
|
|
|
? |
EG0008 |
• • HARNESS - ACC/PSW |
1 |
|
|
|
|
? |
SG2103 |
• • GROMMET, RUBBER |
2 |
|
|
|
|
? |
AK8289 |
• • NOTE: (1) INCLUDED IN AK8289 PRESSURE SWITCH KIT. |
65535 |
|
|
|
|
? |
EC1015 |
• • (2) INCLUDED IN EC1015 PRESSURE SWITCH KIT. |
65535 |
|
|
|
