| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | EF7595 | • TIE ROD ASSEMBLY | 1 | ||||
| ? | WA6183 | • • BEARING, BALL | 2 | ||||
| ? | EB4427 | • • RETAINER, BEARING | 2 | ||||
| ? | C1602 | • • CAPSCREW - 3/8" - 16NC X 1" | 12 | ||||
| ? | C0312 | • • LOCKWASHER - 3/8" | 12 | ||||
| ? | EC3354 | • • ROD END - R.H. | 1 | ||||
| ? | EC3355 | • • ROD END - L.H. | 1 | ||||
| ? | VN9140 | • • CAPSCREW - 3/4" - 10NC X 4" | 4 | ||||
| ? | VL2993 | • • LOCKNUT - 3/4" - 10NC | 4 | ||||
| ? | EC1599 | • • ROD, TIE | 1 | ||||
| ? | • • STEERING CYLINDER ASSEMBLY (SEE FIG. 55014) | 2 | |||||
| ? | EF7598 | • • PIN, STEERING & TIE ROD (2) | 4 | ||||
| ? | MM0690 | • • CAPSCREW - M20 (1)/(2) | 12 | ||||
| ? | MM0697 | • • NUT - M20 X 2.50 (1)/(2) | 12 | ||||
| ? | EB4430 | • • RETAINER (1)/(2) | 8 | ||||
| ? | EF7599 | • • WASHER (2) | 4 | ||||
| ? | EB4428 | • • SPACER (1)/(2) | 12 | ||||
| ? | EB4429 | • • PIN (1) | 2 | ||||
| ? | WA4817 | • • CAPSCREW - 1 1/4" - 12NF X 5" (12 POINT) | 54 | ||||
| ? | TZ1439 | • • PLATE, RETAINER | 2 | ||||
| ? | TY2149 | • • FLAT WASHER (HARDENED) | 16 | ||||
| ? | EF7951 | • • STEERING ARM - R.H. | 1 | ||||
| ? | EF7952 | • • STEERING ARM - L.H. | 1 | ||||
| ? | WA6183 | • • BEARING, SPHERICAL (1)/(2) | 4 | ||||
| ? | AK3731 | • • NOTE: (1) INCLUDED IN AK3731 STEERING PIN KIT. | 65535 | ||||
| ? | AK3732 | • • (2) INCLUDED IN AK3732 STRG CYL & TIE ROD PIN KIT. | 65535 |
