| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | • SEAL, DUST (1) | 1 | |||||
| ? | VE3080 | • • HOUSING/SPOOL/SLEEVE | 1 | ||||
| ? | VE3081 | • • BALL - 8.5 MM/0.33" | 1 | ||||
| ? | VE3082 | • • BUSHING, THREADED | 1 | ||||
| ? | • • O-RING (1) | 1 | |||||
| ? | • • KIN-RING (1) | 1 | |||||
| ? | VE3083 | • • BEARING ASSEMBLY | 1 | ||||
| ? | VE3084 | • • RING | 1 | ||||
| ? | VE3085 | • • CROSS PIN | 1 | ||||
| ? | VE3086 | • • SPRING SET | 1 | ||||
| ? | VE3087 | • • SHAFT, CARDAN | 1 | ||||
| ? | VE3094 | • • SPACER | 1 | ||||
| ? | VE3088 | • • SPACER - 33.5 MM/1.32" | 1 | ||||
| ? | • • O-RING (1) | 1 | |||||
| ? | VE3089 | • • PLATE, DISTRIBUTOR | 1 | ||||
| ? | VE3090 | • • GEAR WHEEL SET | 1 | ||||
| ? | • • O-RING (1) | 2 | |||||
| ? | VE3091 | • • COVER, END | 1 | ||||
| ? | • • WASHER (1) | 7 | |||||
| ? | VE3092 | • • PIN, ROLL | 1 | ||||
| ? | VE3093 | • • CAPSCREW - M8 X 90 MM | 1 | ||||
| ? | MM0401 | • • CAPSCREW - M8 X 1.25 X 90 | 6 | ||||
| ? | • • NAME PLATE (2) | 1 | |||||
| ? | • • DRIVE SCREW (2) | 2 | |||||
| ? | VE3095 | • • NOTE: (1) INCLUDED IN VE3095 SEAL KIT. | 65535 | ||||
| ? | • • (2) NOT SERVICED SEPARATELY. | 65535 |
