| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VE9458 | • ARMATURE ASSEMBLY | 1 | ||||
| ? | BF0097 | • • SHAFT | 1 | ||||
| ? | BF0998 | • • ARMATURE HEAD | 1 | ||||
| ? | VE4818 | • • PUNCHING, MAIN - 0.0185" THICK | 256 | ||||
| ? | VE4819 | • • PUNCHING, END - 0.0673" THICK | 4 | ||||
| ? | VE2761 | • • REWIND KIT, ARMATURE | 1 | ||||
| ? | BF1001 | • • PERMAFIL PUTTY | 65535 | ||||
| ? | VE7206 | • • GLASS TAPE - 0.014" THICK, 3/8" WIDE | 1 | ||||
| ? | VE4696 | • • LOCKWASHER - 5/16" | 6 | ||||
| ? | TR4731 | • • CAPSCREW - 5/16" - 18NC X 1" | 6 | ||||
| ? | VS8884 | • • NUT - 1 11/16" - 16 | 1 | ||||
| ? | VS9031 | • • LOCKWASHER - 1 23/32" ID | 1 | ||||
| ? | H2982 | • • BALL BEARING | 1 | ||||
| ? | VS9032 | • • FLINGER, LUBRICANT | 1 | ||||
| ? | VS7492 | • • ADHESIVE, RTV SILMATE 1473 | 65535 | ||||
| ? | VS9221 | • • BEARING CAP | 1 | ||||
| ? | BF1885 | • • FRAME HEAD | 1 | ||||
| ? | VE4257 | • • FAN | 1 | ||||
| ? | VS9062 | • • NUT - 1 1/8" - 18 | 1 | ||||
| ? | BF1889 | • • COTTER PIN | 1 | ||||
| ? | VS0961 | • • BALANCE WEIGHT | 1 | ||||
| ? | VE4687 | • • LOCKWASHER - 3/8" | 8 | ||||
| ? | VE4641 | • • CAPSCREW - 3/8" - 16NC X 1 1/4" | 8 | ||||
| ? | C1630 | • • CAPSCREW - 5/8" - 11NC X 2" | 16 | ||||
| ? | VC1390 | • • LOCKWASHER - 5/8" | 16 |
