| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VE3530 | • SENSOR, POSITION | 1 | ||||
| ? | BF0018 | • • BOX | 1 | ||||
| ? | VE1142 | • • PIN - 1/16" X 3/8" | 2 | ||||
| ? | VE1142 | • • PIN - 1/16" X 3/8" | 1 | ||||
| ? | VE0995 | • • INNER ARM ASSEMBLY | 1 | ||||
| ? | VE0375 | • • SPRING | 1 | ||||
| ? | VE5751 | • • MACHINE SCREW - #4 - 40NC X 5/8" | 1 | ||||
| ? | VE4908 | • • LOCKWASHER - #4 | 1 | ||||
| ? | VE4909 | • • NUT - #4 - 40NC | 1 | ||||
| ? | VE1143 | • • SPRING | 1 | ||||
| ? | VE4405 | • • STUD ASSEMBLY | 1 | ||||
| ? | VE4406 | • • STUD ASSEMBLY | 1 | ||||
| ? | VE5752 | • • STUD - TAPPED | 1 | ||||
| ? | VE5753 | • • MACHINE SCREW - #4 - 40NC X 1/4" | 1 | ||||
| ? | VE4908 | • • LOCKWASHER - #4 | 1 | ||||
| ? | VE4907 | • • FLAT WASHER - #4 | 1 | ||||
| ? | BF0020 | • • SCREW, SL PAN HEAD - #6 X 5/8" | 5 | ||||
| ? | TR5445 | • • LOCKWASHER - 1/2" | 5 | ||||
| ? | HE5125 | • • FLAT WASHER - #6 | 5 | ||||
| ? | VE5757 | • • OUTER ARM ASSEMBLY | 1 | ||||
| ? | SF2755 | • • NUT, HEX - #10 - 32NF | 3 | ||||
| ? | VC1390 | • • LOCKWASHER - 5/8" | 3 | ||||
| ? | VS6662 | • • FLAT WASHER - #10 | 3 | ||||
| ? | BF3174 | • • COVER | 1 |
