| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VE1319 | WINDOW - R.H. (THERMOPANE) | 1 | ||||
| ? | VS7558 | SLIDING WINDOW - L.H. (SEE FOLLOWING PG) | 1 | ||||
| ? | VE6891 | CAPSCREW | 14 | ||||
| ? | VE6892 | LOCKWASHER - 1/4" | 14 | ||||
| ? | VE0453 | NUT, ACORN - 1/4" - 20NC | 14 | ||||
| ? | VS6269 | HINGE - R.H. | 2 | ||||
| ? | VS6271 | HINGE - L.H. | 2 | ||||
| ? | VS6270 | HINGE - R.H. | 1 | ||||
| ? | VS6272 | HINGE - L.H. | 1 | ||||
| ? | VE0455 | NUT, ACORN - 3/8" - 16NC | 1 | ||||
| ? | VE0313 | REST, ARM | 1 | ||||
| ? | TD0794 | CAPSCREW - 5/16" - 18NC X 3/4" | 2 | ||||
| ? | TV0177 | FLAT WASHER - 5/16" | 2 | ||||
| ? | VS6081 | SUPPORT - R.H. | 1 | ||||
| ? | VS6082 | SUPPORT - L.H. | 1 | ||||
| ? | NSS | INSULATION, DOOR | 1 | ||||
| ? | VS6103 | COVER | 1 | ||||
| ? | VS6244 | SEAL, DOOR | 1 | ||||
| ? | VE0254 | MACHINE SCREW - 1/4" - 20NC X 1/2" | 8 | ||||
| ? | VE2591 | LIGHTER, CIGAR | 1 | ||||
| ? | VE3186 | TRAY, ASH | 1 | ||||
| ? | (QUANTITIES SHOWN ARE FOR ONE DOOR ASSM ONLY.) |
