| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | AK1427 | WHEEL - 24" X 51" | 1 | ||||
| ? | AK1444 | BAND, BEAD SEAT - 51" | 1 | ||||
| ? | TA2214 | O-RING | 1 | ||||
| ? | AK1490 | FLANGE - 1 X 5 | 2 | ||||
| ? | AK1446 | LOCKRING - 51" | 1 | ||||
| ? | TA2572 | NUT - 1" - 14NF | 24 | ||||
| ? | TA6827 | STUD (SEE FRONT SPINDLE HUB & BRAKE PG) | 24 | ||||
| ? | TN7264 | RETAINER | 12 | ||||
| ? | VS5591 | SPUD | 1 | ||||
| ? | WA2670 | CAP | 1 | ||||
| ? | VJ8012 | HOUSING, CORE | 1 | ||||
| ? | WA4649 | CLAMP | 1 | ||||
| ? | C0312 | LOCKWASHER - 3/8" | 1 | ||||
| ? | C1547 | FLAT WASHER - 3/8" | 1 | ||||
| ? | C1602 | CAPSCREW - 3/8" - 16NC X 1" | 1 | ||||
| ? | PB3091 | TUBE | 1 | ||||
| ? | VS5592 | STEM - 90 DEG (SWIVEL VALVE) | 1 | ||||
| ? | (QUANTITIES SHOWN ARE FOR ONE SIDE ONLY. WHEELS | ||||||
| ? | ARE NOT SOLD AS ASSMS. ORDER COMPONENT PARTS) |
