| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | HOUSING (1) | 1 | |||||
| ? | VS7864 | PISTON | 6 | ||||
| ? | VE1791 | O-RING | 6 | ||||
| ? | VE1792 | RING, BACKUP | 6 | ||||
| ? | VS7529 | BLEEDER SCREW | 2 | ||||
| ? | VS5263 | SHIELD, DUST | 6 | ||||
| ? | VE3909 | LINING, DISC | 2 | ||||
| ? | TX0804 | DISC | 1 | ||||
| ? | VS5264 | LINING, END PLATE - L.H. | 2 | ||||
| ? | VS5265 | LINING, END PLATE - R.H. | 2 | ||||
| ? | VH2851 | CAPSCREW - 3/4" - 16NF X 2" | 12 | ||||
| ? | VS5271 | FLAT WASHER (RECESSED) | 16 | ||||
| ? | VE1794 | CROSS-OVER TUBE ASSEMBLY | 1 | ||||
| ? | • SLEEVE (1) | 2 | |||||
| ? | • NUT (1) | 2 | |||||
| ? | VE1796 | FITTING, ELBOW | 1 | ||||
| ? | VE1795 | FITTING, TEE | 1 | ||||
| ? | VE1797 | CONNECTOR | 2 | ||||
| ? | VS1793 | BLEEDER SCREW (OPPOSITE SIDE OF CALIPHER FROM | 2 | ||||
| ? | ITEM 14) | ||||||
| ? | NOTE: (1) NOT SERVICED SEPARATELY. |
