| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | TA0603 | FITTING, NYLON | 4 | ||||
| ? | C1231 | COUPLING, PIPE | 4 | ||||
| ? | DC5608 | NIPPLE, CLOSE | 4 | ||||
| ? | TZ6804 | TUBE - L.H. | 1 | ||||
| ? | WA1074 | CLAMP, T-BOLT | 4 | ||||
| ? | PB8007 | HOSE, HUMP | 4 | ||||
| ? | TA2945 | CLAMP, T-BOLT | 4 | ||||
| ? | EB2440 | TUBE | 2 | ||||
| ? | EB2438 | TUBE - L.H. | 1 | ||||
| ? | WA1083 | CLAMP, T-BOLT | 16 | ||||
| ? | VW7036 | ELBOW | 4 | ||||
| ? | VW7331 | CLAMP | 2 | ||||
| ? | EB2444 | BRACKET - L.H. | 1 | ||||
| ? | EB2443 | BRACKET - R.H. | 1 | ||||
| ? | WA4726 | FLATWASHER - 3/8" | 12 | ||||
| ? | VW7769 | HOSE, HUMP | 2 | ||||
| ? | EB2439 | TUBE - R.H. | 1 | ||||
| ? | VA5142 | "U" BOLT | 4 | ||||
| ? | TC1233 | NUT - 3/8" - 16NC | 8 | ||||
| ? | TC1231 | LOCKWASHER - 3/8" | 16 | ||||
| ? | C5751 | CAPSCREW - 3/8" - 16NC X 2 1/2" | 8 | ||||
| ? | TZ4828 | BRACKET | 1 | ||||
| ? | EB5275 | BRACKET | 1 | ||||
| ? | TZ6805 | TUBE - R.H. | 1 |
