| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VE3520 | PEDAL | 1 | ||||
| ? | VE4214 | COVER | 1 | ||||
| ? | VJ4023 | RING, RETAINING | 3 | ||||
| ? | VE3517 | ROLLER | 1 | ||||
| ? | VE3505 | ARM, LEVER | 1 | ||||
| ? | VE3508 | GROMMET | 1 | ||||
| ? | VE4218 | CLAMP | 2 | ||||
| ? | VE4213 | SCREW - PAN HEAD | 5 | ||||
| ? | VE4219 | SCREW - ROUND HEAD | 2 | ||||
| ? | VE3516 | PIN, TREADLE | 1 | ||||
| ? | VE4217 | SPRING | 1 | ||||
| ? | VE3510 | BUSHING | 2 | ||||
| ? | VE3504 | BUSHING | 3 | ||||
| ? | VJ4256 | PIN, ROLL | 1 | ||||
| ? | VE3513 | SPRING | 1 | ||||
| ? | VE3512 | SPRING | 1 | ||||
| ? | VE3514 | SHAFT | 1 | ||||
| ? | VE3507 | TUBE, SPRING | 1 | ||||
| ? | VE4215 | PLATE, BASE 28 DEG - F | 1 | ||||
| ? | VE4216 | PIN, ROLLER | 1 | ||||
| ? | VE3506 | SHIM, LEVER | 1 | ||||
| ? | VE3519 | BEARING | 1 | ||||
| ? | VE3503 | WASHER | 2 | ||||
| ? | VE3518 | COVER PLATE, POTENTIOMETER | 1 | ||||
| ? | VE3522 | SCREW - ROUND HEAD | 2 | ||||
| ? | VE3523 | POTENTIOMETER | 1 |
