| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | BODY (1) | 1 | |||||
| ? | TH7523 | CAPSCREW - 5/16" - 18NC X 1/2" | 4 | ||||
| ? | SC4174 | LOCKWASHER - 5/16" | 4 | ||||
| ? | VS6765 | VALVE, SHUT-OFF | 1 | ||||
| ? | VJ7251 | BOLT, SEAT | 1 | ||||
| ? | VS6764 | SEAT, WASHER | 1 | ||||
| ? | SEAT, VALVE (2) | 2 | |||||
| ? | VJ7253 | SPACER, SEAT | 1 | ||||
| ? | O-RING (2) | 2 | |||||
| ? | VS6763 | PISTON | 1 | ||||
| ? | O-RING (2) | 1 | |||||
| ? | H8065 | CAPSCREW - 1/4" - 20NC X 3/4" | 3 | ||||
| ? | ADAPTOR (1) | 1 | |||||
| ? | GASKET (2) | 1 | |||||
| ? | R5116 | PIPE, REDUCER | 1 | ||||
| ? | O-RING (1) | 1 | |||||
| ? | VJ7986 | SPRING & CAP ASSEMBLY | 1 | ||||
| ? | VJ7255 | • WASHER, SEAT | 1 | ||||
| ? | VJ7135 | • SPRING, LARGE | 1 | ||||
| ? | VJ7987 | • SPRING, SMALL | 1 | ||||
| ? | VJ7257 | • BOLT, SHOULDER | 1 | ||||
| ? | VJ7256 | • CAP, SPRING | 1 | ||||
| ? | VJ7258 | • CAP, DIRT | 1 | ||||
| ? | VS6766 | CLIP, MOUNTING | 1 | ||||
| ? | VY0719 | MACHINE SCREW - #10 - 24NC X 1/2" | 1 | ||||
| ? | R2634 | LOCKWASHER - #10 | 1 | ||||
| ? | VS7007 | HEATER | 1 | ||||
| ? | NOTE: (1) NOT SERVICED SEPARATELY. | ||||||
| ? | RK1899 | (2) INCLUDED IN RK1899 REPAIR KIT. |
