| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | C5746 | CAPSCREW - 1/4" - 20NC X 3/4" | 4 | ||||
| ? | TR1307 | FLAT WASHER - 1/4" | 12 | ||||
| ? | VN9751 | LOCKNUT, NYLON - 1/4" | 9 | ||||
| ? | JG6867 | BLOCK | 1 | ||||
| ? | JG6863 | MOUNTING STR | 1 | ||||
| ? | SF9144 | JAM NUT - 1/4" - 20NC | 3 | ||||
| ? | JG6866 | BRACKET, MOUNTING | 1 | ||||
| ? | C3145 | CAPSCREW - 1/4" - 20NC X 5/8" | 2 | ||||
| ? | CC6807 | LOCKWASHER - 5/8" (INTERNAL TOOTH) | 4 | ||||
| ? | VY4365 | SCREW, SELF-TAPPING - 1/4" - 20NC X 1/2" | 2 | ||||
| ? | VS5359 | SPACER (1) | 1 | ||||
| ? | VS5360 | HANDLE, CONTROL LEVER (1) | 3 | ||||
| ? | VS5370 | CABLE, CONTROL (HEAT/DEFROST) | 2 | ||||
| ? | JG6777 | CABLE, CONTROL (FRESH AIR) | 1 | ||||
| ? | VS7171 | CABLE, CONTROL (AIR CONDITIONER) | 1 | ||||
| ? | PB4978 | VALVE, CONTROL | 1 | ||||
| ? | TN9903 | HOSE | 1 | ||||
| ? | HC0908 | CLAMP, HOSE | 2 | ||||
| ? | WA3697 | CLAMP, CABLE (1) | 3 | ||||
| ? | VS5358 | KNOB, CONTROL (1) | 3 | ||||
| ? | PB5727 | • KNOB | 3 | ||||
| ? | WA4198 | • MACHINE, SCREW | 3 | ||||
| ? | C1602 | CAPSCREW - 3/8" - 16NC X 1" | 2 | ||||
| ? | H5304 | LOCKWASHER, INTERNAL TOOTH - 3/8" | 2 | ||||
| ? | WA0720 | FLAT WASHER - 3/8" | 2 | ||||
| ? | JG6868 | ROD, THREADED | 1 | ||||
| ? | C5780 | NUT - 1/4" - 20NC | 2 | ||||
| ? | NOTE: (1) QUANTITIES SHOWN ARE FOR HEATER APPLICATION | ||||||
| ? | IF AIR CONDITIONER IS INCLUDED ADD ONE EACH. |
