Номер на схеме	Каталожный номер	Название	Количество
?	R4186	FITTING, GREASE	11
?	TW2611	COUPLING	1
?	SV7053	ADAPTOR, STRAIGHT	11
?	HA9410	HOSE (TO TOP OF HOIST CYLINDERS)	2
?	SV7053	ADAPTOR, STRAIGHT (AT TOP OF HOIST CYLINDERS)	2
?	VZ4843	STRAP, TIE	2
?	HA9442	HOSE (TO BOTTOM OF HOIST CYLINDERS)	2
?	VH0596	ELBOW - 90 DEG (AT BOTTOM OF HOIST CYLINDERS)	2
?	DC5608	NIPPLE, CLOSE (AT BOTTOM OF HOIST CYLINDERS)	2
?	C1231	COUPLING, PIPE (AT BOTTOM OF HOIST CYLINDERS)	2
?	HA9439	HOSE (TO DRIVE AXLE PIVOT PIN)	1
?	DL2660	ELBOW - 45 DEG	1
?	HA9432	HOSE (TO FRONT OF ANTI-SWAY BAR)	1
?	VH0596	ELBOW - 90 DEG (AT LEFT FRONT OF ANTI-SWAY BAR)	1
?	C1231	COUPLING, PIPE (AT LEFT FRONT OF ANTI-SWAY BAR)	1
?	CD3705	NIPPLE, LONG (AT LEFT FRONT OF ANTI-SWAY BAR)	1
?	HA0511	HOSE (TO RIGHT REAR OF ANTI-SWAY BAR)	1
?	VH0596	ELBOW - 90 DEG (AT RIGHT REAR OF ANTI-SWAY BAR)	1
?	HA0511	HOSE (TO TOP OF REAR SUSPENSION)	2
?	VH0596	ELBOW - 90 DEG (AT TOP OF REAR SUSPENSION)	2
?	HA9408	HOSE (TO BODY PIVOT PINS)	2
?	DL2660	ELBOW - 45 DEG (AT BODY PIVOT PINS)	2
