Номер на схеме |
Каталожный номер |
Название |
Количество |
Детали |
|
|
|
? |
WA2953 |
STUD - 1" - 14UNS X 6 1/2" |
35 |
|
|
|
|
? |
VM0315 |
PLUG, O-RING |
1 |
|
|
|
|
? |
C1614 |
CAPSCREW - 1/2" - 13NC X 1 1/2" |
8 |
|
|
|
|
? |
C1540 |
LOCKWASHER - 1/2" |
8 |
|
|
|
|
? |
WA4795 |
SEAL, O-RING (1) |
1 |
|
|
|
|
? |
TY2126 |
COVER, MACHINED |
1 |
|
|
|
|
? |
PB7454 |
GAUGE, SIGHT |
1 |
|
|
|
|
? |
SD5211 |
BUSHING, PIPE |
1 |
|
|
|
|
? |
TH6916 |
VALVE, CHECK |
1 |
|
|
|
|
? |
H6881 |
PLUG, PIPE |
1 |
|
|
|
|
? |
VN2458 |
CAPSCREW - 1" - 8NC X 3 1/2" |
6 |
|
|
|
|
? |
WA0364 |
FLAT WASHER - 1" |
6 |
|
|
|
|
? |
TY2134 |
RETAINER, BEARING |
1 |
|
|
|
|
? |
TY2135 |
SHIM - .002 (1) |
7 |
|
|
|
|
? |
TY2136 |
SHIM - .014 (1) |
2 |
|
|
|
|
? |
TY2137 |
SHIM - .031 (1) |
2 |
|
|
|
|
? |
PB6179 |
CONE, BEARING (1) |
1 |
|
|
|
|
? |
PB6178 |
CUP, BEARING (1) |
1 |
|
|
|
|
? |
EB1725 |
HUB - 57 INCH |
1 |
|
|
|
|
? |
PB5536 |
DISC BRAKE ASSM (SEE INDEX) |
3 |
|
30556 |
|
|
? |
TY6049 |
ADAPTOR, BRAKE |
1 |
|
|
|
|
? |
WA4510 |
CAPSCREW - 1 1/4" - 12NF X 3 1/4" |
24 |
|
|
|
|
? |
TY2149 |
FLAT WASHER (HARDENED) |
78 |
|
|
|
|
? |
EC9920 |
SPINDLE |
1 |
|
|
|
|
? |
PB7008 |
CUP, BEARING (1) |
1 |
|
|
|
|
? |
PB7007 |
CONE, BEARING (1) |
1 |
|
|
|
|
? |
TY8313 |
SPACER |
1 |
|
|
|
|
? |
WA3145 |
PLUG |
1 |
|
|
|
|
? |
PB5756 |
SEAL (1) |
1 |
|
|
|
|
? |
WA4817 |
CAPSCREW - 1 1/4" - 12NF X 5" |
24 |
|
|
|
|
? |
WA4818 |
CAPSCREW - 1 1/4" - 12NF X 4" |
30 |
|
|
|
|
? |
TY7679 |
DISC, BRAKE |
1 |
|
|
|
|
? |
AK7135 |
(2) INCLUDED IN AK7135 SPINDLE MAINTENANCE KIT. |
|
|
|
|
|
? |
|
(QUANTITIES SHOWN ARE FOR ONE SIDE ONLY) |
|
|
|
|
