Номер на схеме |
Каталожный номер |
Название |
Количество |
Детали |
|
|
|
? |
FA7839 |
• TIE ROD ASSM |
1 |
|
|
|
|
? |
PB2011 |
• • BEARING, BALL |
2 |
|
|
|
|
? |
TJ1832 |
• • RETAINER, BEARING |
2 |
|
|
|
|
? |
C1602 |
• • CAPSCREW - 3/8" - 16NC X 1" |
8 |
|
|
|
|
? |
C0312 |
• • LOCKWASHER - 3/8" |
8 |
|
|
|
|
? |
TJ1833 |
• • END, ROD |
1 |
|
|
|
|
? |
VW7203 |
• • CAPSCREW - 3/4" - 10NC X 4" |
2 |
|
|
|
|
? |
VC8946 |
• • SLOTTED NUT - 3/4" - 10NC |
2 |
|
|
|
|
? |
R0194 |
• • PIN, COTTER |
2 |
|
|
|
|
? |
TJ1835 |
• • ROD, TIE |
1 |
|
|
|
|
? |
TJ1829 |
• • SPACER, BEARING |
10 |
|
|
|
|
? |
TZ8114 |
• • PIN, STEERING |
6 |
|
|
|
|
? |
WA0370 |
• • FLAT WASHER - 1 3/4" |
6 |
|
|
|
|
? |
VL7694 |
• • LOCKNUT, NYLON - 1 3/4" - 7NC |
6 |
|
|
|
|
? |
TY9950 |
• • STEERING CLYINDER ASSM (SEE INDEX) |
2 |
|
|
|
|
? |
TZ0278 |
• • STEERING ARM - R.H. |
1 |
|
|
|
|
? |
TZ1433 |
• • STEERING ARM - L.H. |
1 |
|
|
|
|
? |
WA4817 |
• • CAPSCREW - 1 1/4" - 12NF X 5" (12 POINT) |
16 |
|
|
|
|
? |
TZ1439 |
• • PLATE, RETAINING |
2 |
|
|
|
|
? |
TY2149 |
• • FLAT WASHER (HARDENED) |
16 |
|
|
|
|
? |
PB2011 |
• • BUSHING, BALL |
4 |
|
|
|
|
? |
TK4452 |
• • RETAINER, BEARING |
4 |
|
|
|
|
? |
C1602 |
• • CAPSCREW - 3/8" - 16NC X 1" |
24 |
|
|
|
|
? |
C0312 |
• • LOCKWASHER - 3/8" |
24 |
|
|
|
|
? |
TZ8113 |
• • BLOCK, RETAINER |
6 |
|
|
|
|
? |
TZ8112 |
• • PAD, TAPPED |
6 |
|
|
|
