| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | PB8730 | PLATE, HOLD DOWN - ADJUSTABLE | 1 | ||||
| ? | PB9152 | ASSEMBLY, FITTING | 1 | ||||
| ? | PB9153 | ASSEMBLY, FITTING | 1 | ||||
| ? | HA7169 | HOSE - SUCTION | 1 | ||||
| ? | HA7216 | HOSE - DISCHARGE | 1 | ||||
| ? | WA0720 | FLATWASHER - 3/8" | 11 | ||||
| ? | C1604 | CAPSCREW - 3/8" - 16NC X 1 1/2" | 13 | ||||
| ? | C1521 | NUT - 3/8" | 6 | ||||
| ? | ED7063 | BRACKET - FRONT | 1 | ||||
| ? | PB9069 | COMPRESSOR | 1 | ||||
| ? | MM0067 | CAPSCREW - M10 X 1.50 X 50 | 4 | ||||
| ? | MM0704 | FLATWASHER - M10 | 8 | ||||
| ? | ED7062 | BRACKET - REAR | 1 | ||||
| ? | C1603 | CAPSCREW - 3/8" - 16NC X 1.25" | 4 | ||||
| ? | ED7061 | BRACKET - REAR ADJUSTABLE | 1 | ||||
| ? | ED7065 | BRACKET - MOUNTING | 1 | ||||
| ? | ED7060 | BRACKET - FRONT ADJUSTABLE | 1 | ||||
| ? | WA0723 | FLATWASHER - 3/8" - (HARDENED) | 4 | ||||
| ? | C7568 | CAPSCREW - 3/8" | 4 | ||||
| ? | EF1607 | GUARD, BELT | 1 | ||||
| ? | MM0714 | FLATWASHER - M12 (HARDENED) | 3 | ||||
| ? | C1602 | CAPSCREW - 3/8" - 16NC X 1" | 3 | ||||
| ? | 0125231225 | BOLT | 3 | ||||
| ? | MM0071 | CAPSCREW - M16 X 2.00 X 45 | 2 | ||||
| ? | MM0474 | LOCKWASHER - 16M | 2 | ||||
| ? | MM0706 | FLATWASHER (HARDENED) | 2 | ||||
| ? | ED8107 | LINK | 2 | ||||
| ? | ED7073 | PULLEY | 1 | ||||
| ? | MM0050 | CAPSCREW - M10 X 1.50 X 35 | 3 | ||||
| ? | PB9254 | BELT | 1 | ||||
| ? | EF1608 | PLATE, MOUNTING | 1 | ||||
| ? | WA1732 | O-RING | 2 |
