| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | YA2986 | PANEL, INSTRUMENT | 1 | ||||
| ? | SP8443 | BULB, LIGHT | 20 | ||||
| ? | PB6303 | GAUGE, WATER TEMPERATURE | 1 | ||||
| ? | PB6401 | OVERLAY KIT, BEZEL | 8 | ||||
| ? | PB8551 | GAUGE, OIL PRESSURE | 1 | ||||
| ? | PB6927 | GAUGE, VOLTMETER | 1 | ||||
| ? | PB6985 | SPEEDOMETER, DIGITAL | 1 | ||||
| ? | PB6402 | OVERLAY KIT, BEZEL | 2 | ||||
| ? | TW5472 | LIGHT, TURN INDICATOR | 2 | ||||
| ? | VZ5080 | LAMP | 7 | ||||
| ? | WA6639 | LEXAN OVERLAY, TURN SIGNAL | 1 | ||||
| ? | TY8743 | PANEL, INSERT - TURN SIGNAL | 1 | ||||
| ? | WA4605 | PHILLIPS SCREW - #10 - 24NC X 1/2" | 27 | ||||
| ? | TW3834 | INDICATOR, HIGH-BEAM | 1 | ||||
| ? | PB6984 | TACHOMETER, DIGITAL | 1 | ||||
| ? | WA6637 | LIGHT CLUSTER | 4 | ||||
| ? | CH1503 | LIGHT INSERT | 1 | ||||
| ? | WA4877 | MACHINE SCREW (FLAT HEAD) | 8 | ||||
| ? | CH1511 | LIGHT INSERT | 1 | ||||
| ? | WA6640 | LEXAN OVERLAY, TEST SWITCH | 1 | ||||
| ? | TX6341 | PANEL, INSERT - TEST SWITCH | 1 | ||||
| ? | PB6969 | SWITCH, ROCKER | 1 | ||||
| ? | CH1506 | LIGHT INSERT | 1 | ||||
| ? | CH1509 | LIGHT, INSERT | 1 | ||||
| ? | PB7019 | LIGHT, INDICATOR | 3 | ||||
| ? | VL6234 | LAMP | 3 | ||||
| ? | PB6972 | SWITCH, ROCKER | 5 | ||||
| ? | EB2431 | PANEL, INSERT | 1 | ||||
| ? | WB0966 | LEXAN OVERLAY, KEY SWITCH | 1 | ||||
| ? | TY8749 | PANEL, INSERT - BLANK | 1 | ||||
| ? | EB9458 | COVER, PLATE | 1 | ||||
| ? | VM7105 | SWITCH, KEY | 1 | ||||
| ? | TW5117 | RHEOSTAT | 1 | ||||
| ? | PB0529 | KNOB, RHEOSTAT | 1 | ||||
| ? | TY9878 | CONTROL, ELECTRIC WIPER | 1 | ||||
| ? | PB7026 | SWITCH, ROCKER | 1 | ||||
| ? | WA6651 | LEXAN OVERLAY, SWITCH | 1 | ||||
| ? | TY8741 | PANEL, INSERT - SWITCH | 1 | ||||
| ? | PB6307 | HOURMETER | 1 | ||||
| ? | (NOT USED THIS APPLICATION) | ||||||
| ? | PB6926 | GAUGE, FUEL LEVEL | 1 | ||||
| ? | WA6652 | LEXAN OVERLAY, BRAKE | 1 | ||||
| ? | TY8742 | PANEL, INSERT - BRAKE | 1 | ||||
| ? | VJ8676 | SWITCH, HEATER | 1 | ||||
| ? | VJ8323 | KNOB | 1 | ||||
| ? | WA6644 | LEXAN OVERLAY, HEATER | 1 | ||||
| ? | TX6371 | PANEL, INSERT - HEATER | 1 | ||||
| ? | PB9708 | GAUGE, AIR CLEANER VACUUM | 2 | ||||
| ? | WA0085 | O-RING | 2 | ||||
| ? | WB2133 | CHART, GRADE SPEED | 1 | ||||
| ? | PB6972 | SWITCH, ROCKER - FOG LIGHTS (OPTIONAL) | 1 | ||||
| ? | EF2449 | HARNESS, MAIN (1) | 1 | ||||
| ? | TY7842 | WIRE & SOCKET -P1-R1 (1) | 1 | ||||
| ? | TY7841 | WIRE & SOCKET -P2-R2 (1) | 1 | ||||
| ? | PB7903 | LOUVER, BALL - W/ 2.50 HOSE | 2 | ||||
| ? | PB8164 | SWITCH,- EMERGENCY ENGINE SHUTDOWN | 1 | ||||
| ? | PB9050 | HOSE, VACUUM EPDM | 2 | ||||
| ? | PB9051 | FITTING, SINGLE BARB W/FILTER | 4 | ||||
| ? | PB9056 | FITTING, COMPRESSION FEMALE | 2 | ||||
| ? | C1231 | COUPLING, PIPE | 2 | ||||
| ? | (NOT USED THIS APPLICATION) | ||||||
| ? | PB6343 | PLUG, BUTTON | 1 | ||||
| ? | PB6982 | BLANK, INSERT | 1 | ||||
| ? | NOTE: (1) LOCATED ON BACK OF INSTRUMENT PANEL. |
