| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | FRAME, MAIN (ORDER FROM FACTORY) | 1 | |||||
| ? | ED5930 | UPRIGHT - R.H. | 1 | ||||
| ? | YA3135 | UPRIGHT - L.H. | 1 | ||||
| ? | SH5272 | CAPSCREW - 5/8" - 11NC X 6" | 12 | ||||
| ? | C1525 | NUT - 5/8" - 11NC | 12 | ||||
| ? | ED6340 | SUB-FRAME - R.H. | 1 | ||||
| ? | TY6172 | TUBE, ROPS | 1 | ||||
| ? | TY6171 | MOUNT, ROPS | 1 | ||||
| ? | C1667 | CAPSCREW - 1" - 8NC X 2 1/2" | 16 | ||||
| ? | WA0364 | FLATWASHER - 1" | 16 | ||||
| ? | MM0091 | CAPSCREW - M20 X 2.5 X 30 | 8 | ||||
| ? | MM0707 | FLATWASHER - M20 | 8 | ||||
| ? | ED6344 | SUB-FRAME - L.H. | 1 | ||||
| ? | ED6857 | PLATE - R.H. | 1 | ||||
| ? | ED6856 | PLATE - L.H. | 1 | ||||
| ? | ED6858 | BACKER | 4 | ||||
| ? | EB2093 | MOUNT, ROPS | 1 | ||||
| ? | YA3153 | SUPPORT | 1 | ||||
| ? | ED6872 | BACKER L.H. | 2 | ||||
| ? | ED6873 | BACKER R.H. | 2 | ||||
| ? | ED6859 | PLATE, MOUNT - RIGHT OUTER | 1 | ||||
| ? | ED6860 | PLATE, MOUNT - RIGHT INTER | 1 | ||||
| ? | ED6863 | PLATE, MOUNT - LEFT INTER | 1 | ||||
| ? | ED6862 | PLATE, MOUNT - LEFT OUTER | 1 | ||||
| ? | NS = NOT SHOWN | ||||||
| ? | PB2849 | EXTINGUISHER, FIRE | 1 | ||||
| ? | PB2850 | BRACKET, FENDER | 1 | ||||
| ? | VW6804 | PAD, TAPPED | 1 | ||||
| ? | C0312 | LOCKWASHER - 3/8" | 3 | ||||
| ? | H8524 | CAPSCREW - 3/8" - 16NC X 5/8" | 3 |
