| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | YA3098 | HOUSING, AXLE | 1 | ||||
| ? | EC4617 | ANTI-SWAY BAR (2) | 1 | ||||
| ? | VN9106 | CAPSCREW - 1 1/4" - 7NC X 3" | 24 | ||||
| ? | WA0366 | FLATWASHER - 1 1/4" (HARDENED) | 24 | ||||
| ? | TY4008 | EYE, PIVOT (1) | 1 | ||||
| ? | TY7704 | RING, COVER | 2 | ||||
| ? | TY1344 | RETAINER, BEARING | 2 | ||||
| ? | TY1345 | SPACER | 2 | ||||
| ? | C5764 | CAPSCREW - 3/4" - 10NC X 6" | 8 | ||||
| ? | VL2993 | LOCKNUT - 3/4" - 10NC | 10 | ||||
| ? | TY1346 | PIN, PIVOT | 1 | ||||
| ? | PB6612 | BEARING (1) | 1 | ||||
| ? | TY1343 | CARRIER, BEARING (1) | 1 | ||||
| ? | TY1347 | PLATE, LOCKING | 1 | ||||
| ? | EC8134 | CAPSCREW - 1" - 13NC X 3 1/4" (DRILLED HEAD) | 4 | ||||
| ? | WA0364 | FLATWASHER - 1" (HARDENED) | 4 | ||||
| ? | C1633 | CAPSCREW - 5/8" - 11NC X 2 3/4" | 3 | ||||
| ? | C1541 | LOCKWASHER - 5/8" | 5 | ||||
| ? | VL4462 | WIRE, GROUND | 1 | ||||
| ? | VH9969 | STUD, WELD - 3/8" - 16NC X 3/4" | 2 | ||||
| ? | C0312 | LOCKWASHER - 3/8" | 2 | ||||
| ? | C1521 | NUT - 3/8" - 16NC | 2 | ||||
| ? | TX8110 | SLEEVE | 4 | ||||
| ? | EC4615 | PIN, BEARING | 2 | ||||
| ? | VN9211 | CAPSCREW - 3/4" - 10NC X 7 1/2" | 2 | ||||
| ? | TY2734 | SPACER | 4 | ||||
| ? | VN9351 | RING, RETAINING (2) | 4 | ||||
| ? | PB0027 | BEARING (2) | 2 | ||||
| ? | CE2510 | CAPSCREW - 5/8" - 11NC X 3/4" | 2 | ||||
| ? | VN3270 | CAPSCREW - 1 1/4" - 7NC X 5" | 96 | ||||
| ? | WA0366 | FLATWASHER - 1 1/4" (HARDENED) | 96 | ||||
| ? | NOTE: (1) INCLUDED IN TY4011 PIVOT EYE ASSM. | ||||||
| ? | (2) INCLUDED IN EC5272 ANTI-SWAY BAR W/ BEARINGS ASSM. |
