| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | C1613 | CAPSCREW - 1/2" - 13NC X 1 1/4" | 23 | ||||
| ? | C1540 | LOCKWASHER - 1/2" | 31 | ||||
| ? | WA0360 | FLATWASHER - 1/2" | 13 | ||||
| ? | YA1053 | COVER, SURGE TANK | 1 | ||||
| ? | VG7811 | LOCKNUT, NYLON - 1/2" - 13NC | 1 | ||||
| ? | VC7836 | FLATWASHER - 1/2" | 2 | ||||
| ? | TY7528 | PLATE, COVER | 1 | ||||
| ? | PB6877 | LEVER, NUT | 1 | ||||
| ? | PB6842 | HOOK, RUBBER HOOD | 2 | ||||
| ? | C1639 | CAPSCREW - 5/16" - 18NC X 2" | 2 | ||||
| ? | VN9951 | LOCKNUT - 5/16" - 18NC | 2 | ||||
| ? | EF7029 | GRILLE FRAME | 1 | ||||
| ? | ED8140 | GRILLE | 2 | ||||
| ? | TY7538 | CLIP | 20 | ||||
| ? | WA3364 | LOCKSCREW | 20 | ||||
| ? | TY9672 | CHANNEL, RUBBER - AIR DAM | 2 | ||||
| ? | VN6450 | CAPSCREW - 3/8" - 16NC X 7/8" | 19 | ||||
| ? | C1547 | FLATWASHER - 3/8" | 19 | ||||
| ? | TY7535 | CHANNEL, RUBBER - AIR DAM | 1 | ||||
| ? | C5542 | CAPSCREW - 1 1/4" - 7NC X 3" | 2 | ||||
| ? | WA0366 | FLATWASHER - 1 1/4" | 2 | ||||
| ? | TY8055 | PIN, PIVOT | 1 | ||||
| ? | EB8444 | COVER | 1 | ||||
| ? | C1601 | CAPSCREW - 3/8" - 16NC X 3/4" | 4 | ||||
| ? | C0312 | LOCKWASHER - 3/8" | 4 | ||||
| ? | WA4726 | FLATWASHER - 3/8" | 4 | ||||
| ? | C1645 | CAPSCREW - 3/4" - 10NC X 2 1/4" | 6 | ||||
| ? | C1542 | LOCKWASHER - 3/4" | 14 | ||||
| ? | TY8058 | PIVOT, ENGINE | 1 | ||||
| ? | VM3891 | BUSHING, RUBBER | 4 | ||||
| ? | C1648 | CAPSCREW - 3/4" - 10NC X 3" | 8 | ||||
| ? | WA0362 | FLATWASHER - 3/4" | 8 | ||||
| ? | C1527 | NUT - 3/4" - 10NC | 8 | ||||
| ? | EC3738 | HANDRAIL - FRONT CENTER | 1 | ||||
| ? | C1612 | CAPSCREW - 1/2" - 13NC X 1" | 8 | ||||
| ? | TY8388 | BLOCK, TAPPED | 4 | ||||
| ? | ED8273 | PLATE, COVER | 2 | ||||
| ? | TC1231 | LOCKWASHER - 3/8" | 8 | ||||
| ? | TC1234 | CAPSCREW - 3/8" - 16NC X 3/4" | 8 | ||||
| ? | EC4149 | GRILLE - L.H. | 1 | ||||
| ? | EC4148 | GRILLE - R.H. | 1 |
