Номер на схеме |
Каталожный номер |
Название |
Количество |
Детали |
|
|
|
? |
EB1716 |
HOUSING, FRONT WHEEL |
1 |
|
|
|
|
? |
PB7362 |
DISC BRAKE ASSEMBLY (SEE INDEX) |
3 |
|
11765 |
|
|
? |
YA0447 |
SUPPORT, BRAKE |
1 |
|
|
|
|
? |
WA4682 |
CAPSCREW - 1" - 14NF X 14 1/2" |
18 |
|
|
|
|
? |
WA0364 |
FLATWASHER - 1" |
30 |
|
|
|
|
? |
VN7703 |
NUT - 1" - 14NF |
18 |
|
|
|
|
? |
VM8258 |
CAPSCREW - 1" - 8NC X 3 3/4" |
18 |
|
|
|
|
? |
PB7003 |
CUP, BEARING (1) |
1 |
|
|
|
|
? |
PB7002 |
CONE, BEARING (1) |
1 |
|
|
|
|
? |
YA1078 |
SPINDLE |
1 |
|
|
|
|
? |
EB1715 |
SPACER |
1 |
|
|
|
|
? |
PB5756 |
SEAL ASSEMBLY (1) |
1 |
|
|
|
|
? |
VN9143 |
CAPSCREW - 1 1/4" - 7NC X 4" |
64 |
|
|
|
|
? |
TY2149 |
FLATWASHER (HARDENED) |
64 |
|
|
|
|
? |
TX4848 |
DISC |
1 |
|
|
|
|
? |
TY1633 |
STUD - 1" - 14UNS X 7 1/4" |
35 |
|
|
|
|
? |
PB6218 |
CUP, BEARING (1) |
1 |
|
|
|
|
? |
PB6217 |
CONE, BEARING (1) |
1 |
|
|
|
|
? |
H6881 |
PLUG, PIPE |
1 |
|
|
|
|
? |
TH6916 |
VALVE, CHECK (1) |
1 |
|
|
|
|
? |
TY2148 |
FLAT WASHER (HARDENED) |
6 |
|
|
|
|
? |
TY2134 |
BEARING, RETAINER |
1 |
|
|
|
|
? |
WA4795 |
SEAL, O-RING (1) |
1 |
|
|
|
|
? |
C1616 |
CAPSCREW - 1/2" - 13NC X 2" |
8 |
|
|
|
|
? |
C1540 |
LOCKWASHER - 1/2" |
8 |
|
|
|
|
? |
TY2126 |
COVER |
1 |
|
|
|
|
? |
TY2135 |
SHIM - .002 (1) |
11 |
|
|
|
|
? |
TY2136 |
SHIM - .014 (1) |
2 |
|
|
|
|
? |
TY2137 |
SHIM - .031 (1) |
6 |
|
|
|
|
? |
WA0362 |
FLATWASHER - 3/4" |
8 |
|
|
|
|
? |
TX0807 |
ANGLE |
1 |
|
|
|
|
? |
TH7593 |
FITTING, ELBOW - 90 DEG |
1 |
|
|
|
|
? |
TX0805 |
TUBE |
1 |
|
|
|
|
? |
VY8331 |
CLAMP |
1 |
|
|
|
|
? |
DC7524 |
CAPSCREW - 3/8" - 16NC X 7/8" |
1 |
|
|
|
|
? |
WA0720 |
FLATWASHER - 3/8" |
1 |
|
|
|
|
? |
C0312 |
LOCKWASHER - 3/8" |
1 |
|
|
|
|
? |
C1521 |
NUT - 3/8" - 16NC |
1 |
|
|
|
|
? |
TF5190 |
FITTING, TUBE CONNECTOR |
3 |
|
|
|
|
? |
TX0808 |
BLEEDER, REMOTE |
2 |
|
|
|
|
? |
R2028 |
PLUG, PIPE |
1 |
|
|
|
|
? |
PB7509 |
SCREW, BLEEDER |
2 |
|
|
|
|
? |
TZ7612 |
BOSS, BLEEDER REMOTE |
1 |
|
|
|
|
? |
PB7584 |
SCREW, BLEEDER |
2 |
|
|
|
|
? |
WB0372 |
FITTING, ELBOW - 90 DEG |
2 |
|
|
|
|
? |
WB0576 |
FITTING, STRAIGHT ADAPTOR |
2 |
|
|
|
|
? |
TZ7732 |
TUBE - L.H. |
1 |
|
|
|
|
? |
TZ7733 |
TUBE - R.H. |
1 |
|
|
|
|
? |
PB7454 |
GAUGE, SIGHT |
1 |
|
|
|
|
? |
SD5211 |
BUSHING, PIPE |
1 |
|
|
|
|
? |
AK7471 |
NOTE: (1) INCLUDED IN AK7471 BEARING KIT. |
|
|
|
|
|
? |
|
(QUANTITIES SHOWN ARE FOR ONE SIDE ONLY) |
|
|
|
|
