Номер на схеме |
Каталожный номер |
Название |
Количество |
Детали |
|
|
|
? |
EB1716 |
• HOUSING, FRONT WHEEL |
1 |
|
|
|
|
? |
PB7362 |
• • DISC BRAKE ASSM (SEE INDEX) |
3 |
|
|
|
|
? |
YA0447 |
• • SUPPORT, BRAKE |
1 |
|
|
|
|
? |
WA4682 |
• • CAPSCREW - 1" - 14NF X 14 1/2" |
18 |
|
|
|
|
? |
WA0364 |
• • FLAT WASHER - 1" |
30 |
|
|
|
|
? |
VN7703 |
• • NUT - 1" - 14NF |
18 |
|
|
|
|
? |
VM8258 |
• • CAPSCREW - 1" - 8NC X 3 3/4" |
18 |
|
|
|
|
? |
PB7003 |
• • CUP, BEARING (1) |
1 |
|
|
|
|
? |
PB7002 |
• • CONE, BEARING (1) |
1 |
|
|
|
|
? |
YA1078 |
• • SPINDLE |
1 |
|
|
|
|
? |
EB1715 |
• • SPACER |
1 |
|
|
|
|
? |
PB5756 |
• • SEAL ASSM (1) |
1 |
|
|
|
|
? |
VN9143 |
• • CAPSCREW - 1 1/4" - 7NC X 4" |
64 |
|
|
|
|
? |
TY2149 |
• • FLAT WASHER (HARDENED) |
64 |
|
|
|
|
? |
TX4848 |
• • DISC |
1 |
|
|
|
|
? |
TY1633 |
• • STUD - 1" - 14UNS X 7 1/4" |
35 |
|
|
|
|
? |
PB6218 |
• • CUP, BEARING (1) |
1 |
|
|
|
|
? |
PB6217 |
• • CONE, BEARING (1) |
1 |
|
|
|
|
? |
H6881 |
• • PLUG, PIPE |
1 |
|
|
|
|
? |
TH6916 |
• • VALVE, CHECK (1) |
1 |
|
|
|
|
? |
TY2148 |
• • FLAT WASHER (HARDENED) |
6 |
|
|
|
|
? |
TY2134 |
• • BEARING, RETAINER |
1 |
|
|
|
|
? |
WA4795 |
• • SEAL, O-RING (1) |
1 |
|
|
|
|
? |
C1616 |
• • CAPSCREW - 1/2" - 13NC X 2" |
8 |
|
|
|
|
? |
C1540 |
• • LOCKWASHER - 1/2" |
8 |
|
|
|
|
? |
TY2126 |
• • COVER |
1 |
|
|
|
|
? |
TY2135 |
• • SHIM - .002 (1) |
11 |
|
|
|
|
? |
TY2136 |
• • SHIM - .014 (1) |
2 |
|
|
|
|
? |
TY2137 |
• • SHIM - .031 (1) |
6 |
|
|
|
|
? |
WA0362 |
• • FLAT WASHER - 3/4" |
8 |
|
|
|
|
? |
TX0807 |
• • ANGLE |
1 |
|
|
|
|
? |
TH7593 |
• • FITTING, ELBOW - 90 DEG |
1 |
|
|
|
|
? |
TX0805 |
• • TUBE |
1 |
|
|
|
|
? |
VY8331 |
• • CLAMP |
1 |
|
|
|
|
? |
DC7524 |
• • CAPSCREW - 3/8" - 16NC X 7/8" |
1 |
|
|
|
|
? |
WA0720 |
• • FLAT WASHER - 3/8" |
1 |
|
|
|
|
? |
C0312 |
• • LOCKWASHER - 3/8" |
1 |
|
|
|
|
? |
C1521 |
• • NUT - 3/8" - 16NC |
1 |
|
|
|
|
? |
TF5190 |
• • FITTING, TUBE CONNECTOR |
3 |
|
|
|
|
? |
TX0808 |
• • BLEEDER, REMOTE |
2 |
|
|
|
|
? |
R2028 |
• • PLUG, PIPE |
1 |
|
|
|
|
? |
PB7509 |
• • SCREW, BLEEDER |
2 |
|
|
|
|
? |
TZ7612 |
• • BOSS, BLEEDER REMOTE |
1 |
|
|
|
|
? |
PB7584 |
• • SCREW, BLEEDER |
2 |
|
|
|
|
? |
WB0372 |
• • FITTING, ELBOW - 90 DEG |
2 |
|
|
|
|
? |
WB0576 |
• • FITTING, STRAIGHT ADAPTOR |
2 |
|
|
|
|
? |
TZ7732 |
• • TUBE - L.H. |
1 |
|
|
|
|
? |
TZ7733 |
• • TUBE - R.H. |
1 |
|
|
|
|
? |
PB7454 |
• • GAUGE, SIGHT |
1 |
|
|
|
|
? |
SD5211 |
• • BUSHING, PIPE |
1 |
|
|
|
|
? |
|
• • (QUANTITIES SHOWN ARE FOR ONE SIDE ONLY) |
