| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VE4944 | • HOUSING | 1 | ||||
| ? | VE4945 | • • BEARING | 1 | ||||
| ? | VE4946 | • • ROD,TRIP | 1 | ||||
| ? | VE4947 | • • SCREW | 2 | ||||
| ? | VE4948 | • • PLATE, BUTTERFLY | 1 | ||||
| ? | VE4949 | • • BEARING | 1 | ||||
| ? | VE4950 | • • SPRING, CAMSHAFT | 1 | ||||
| ? | VE6991 | • • BUTTERFLY SHAFT SUB - ASSM | 1 | ||||
| ? | VE4951 | • • O - RING | 1 | ||||
| ? | VE4952 | • • SHAFT | 1 | ||||
| ? | VE4953 | • • PIN, DOWEL | 1 | ||||
| ? | VE4954 | • • NUT | 2 | ||||
| ? | VE4955 | • • GASKET | 1 | ||||
| ? | VE4956 | • • PLATE, COVER | 1 | ||||
| ? | VE4957 | • • SCREW | 4 | ||||
| ? | VE4962 | • • NUT | 4 | ||||
| ? | VE6992 | • • LEVER ARM SUB - ASSM | 1 | ||||
| ? | VE4959 | • • STUD | 1 | ||||
| ? | VE6993 | • • ARM, LEVER | 1 | ||||
| ? | VE4961 | • • RETAINER | 1 | ||||
| ? | VE4958 | • • SPRING, LEVER ARM | 1 | ||||
| ? | VE4857 | • • GASKET | 1 | ||||
| ? | VE4856 | • • SCREW | 2 | ||||
| ? | VE4963 | • • SCREW | 4 | ||||
| ? | VE4858 | • • PIN, DOWEL | 8 | ||||
| ? | VE4892 | • • NOTE: (1) SVCD W/VE4892 VALVE KIT. | 65535 |
