| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | VE7743 | HOUSING (1) | 1 | ||||
| ? | VE7744 | O-RING (1) | 1 | ||||
| ? | VE7745 | BODY, VALVE (1) | 1 | ||||
| ? | TG0501 | O-RING (1)/(4) | 1 | ||||
| ? | VE7746 | VALVE (1)/(4) | 1 | ||||
| ? | VE7747 | U-CUP (1)/(4) | 1 | ||||
| ? | VE7748 | SPRING (1)/(4) | 1 | ||||
| ? | VE7749 | SPRING (1)/(4) | 1 | ||||
| ? | SV2582 | SPRING (1)/(4) | 1 | ||||
| ? | VE7750 | SHAFT, CONTROL (1) | 1 | ||||
| ? | VE7751 | FILTER CARTRIDGE ASSM (1)/(5) | 1 | ||||
| ? | VE7752 | SPRING (1) | 1 | ||||
| ? | VE7753 | PURGE PLATE ASSM (1) | 1 | ||||
| ? | VE7754 | SEAL, WASHER (1)/(3)/(4)/(5) | 1 | ||||
| ? | VE7755 | PLATE NUT, PURGE (1) | 1 | ||||
| ? | VE7756 | O-RING (1)/(3)/(4)/(5) | 1 | ||||
| ? | VE7757 | CAP & COLLAR | 1 | ||||
| ? | VE7758 | COUPLING | 1 | ||||
| ? | VE7759 | DRIVE SCREW | 2 | ||||
| ? | VE7760 | O-RING (1)/(3)/(4)/(5) | 1 | ||||
| ? | VE7761 | COVER PLATE, PURGE VALVE (1) | 1 | ||||
| ? | VE7762 | CLAMP, MOUNTING (7) | 1 | ||||
| ? | VE7763 | INLET, CLOSURE | 2 | ||||
| ? | VE7764 | INLET, CLOSURE | 1 | ||||
| ? | VE7765 | PURGE VALVE/SHAFT ASSM | 1 | ||||
| ? | VE7766 | CLAMP, CABLE | 1 | ||||
| ? | VE7767 | HEATER & THERMOSTAT ASSM (1) | 1 | ||||
| ? | VE7770 | ELBOW - 90 DEG | 1 | ||||
| ? | VE7779 | SEPERATOR, MESH (3) | 1 | ||||
| ? | VE7778 | DESICCANT, PACKAGED (3) | 1 | ||||
| ? | VE7777 | PAD, FILTER | 1 | ||||
| ? | VE7771 | RING, RETAINING (2) | 1 | ||||
| ? | VE7772 | SPRING (2) | 1 | ||||
| ? | VE7773 | O-RING (2) | 1 | ||||
| ? | VE7774 | POPPET (2) | 1 | ||||
| ? | VE7775 | O-RING (3)/(4)/(5) | 1 | ||||
| ? | VE7776 | O-RING (3)/(4)/(5) | 1 | ||||
| ? | VE7768 | DISCONNECT, QUICK (MALE) (7) | 2 | ||||
| ? | VE7769 | DISCONNECT, QUICK (FEMALE) (7) | 2 | ||||
| ? | VE8379 | NOTE: (1) INCLUDED IN VE8379 LOWER HOUSING KIT. | |||||
| ? | VE8380 | (2) INCLUDED IN VE8380 CHECK VALVE KIT. | |||||
| ? | VE8381 | (3) INCLUDED IN VE8381 DESICCANT REPLACEMENT KIT. | |||||
| ? | VE8382 | (4) INCLUDED IN VE8382 PURGE VALVE KIT. | |||||
| ? | VE8383 | (5) INCLUDED IN VE8383 CARTRIDGE REPLACEMENT KIT. | |||||
| ? | VE8384 | (6) INCLUDED IN VE8384 CLAMP KIT. | |||||
| ? | (7) SHIPPED LOOSE, NOT USED IN THIS APPLICATION. |
