| Наименование | Страница | Код страницы |
|---|---|---|
| BRAKE VALVE PEDAL ASSM (PB7402) | 282 | 40901 |
| Номер на схеме | Каталожный номер | Название | Количество | Детали | |||
|---|---|---|---|---|---|---|---|
| ? | PB7402 | BRAKE VALVE PEDAL ASSM (SEE INDEX) | 1 | 40901 | |||
| ? | WB0584 | FITTING, STRAIGHT ADAPTOR | 4 | ||||
| ? | HA5759 | HOSE - RETURN PORT "T" | 1 | ||||
| ? | HA5562 | HOSE - SECONDARY BRAKE PORT "PX" | 1 | ||||
| ? | WB0593 | ADAPTOR, STRAIGHT | 1 | ||||
| ? | WA4201 | FITTING, TUBE | 1 | ||||
| ? | TR1306 | CAPSCREW - 1/4" - 20NC X 1" | 4 | ||||
| ? | DC3584 | LOCKWASHER - 1/4" | 4 | ||||
| ? | TX9593 | PEDAL, BRAKE | 1 | ||||
| ? | BF1856 | PAD, FOOT | 1 | ||||
| ? | TR4731 | CAPSCREW - 5/16" - 18NC X 1" | 4 | ||||
| ? | SC4174 | LOCKWASHER - 5/16" | 4 | ||||
| ? | HA6199 | HOSE - PORT "P1" | 1 | ||||
| ? | HA5937 | HOSE - PORT "B1" | 1 | ||||
| ? | EC2085 | TUBE | 2 | ||||
| ? | TY9643 | TUBE | 1 | ||||
| ? | EC2086 | TUBE | 1 | ||||
| ? | EC2088 | TUBE | 1 | ||||
| ? | TY9646 | TUBE | 1 | ||||
| ? | HA6198 | HOSE - PORT "B2" | 1 | ||||
| ? | HA6198 | HOSE - PORT "P2" | 1 | ||||
| ? | TZ0673 | CLAMP ASSM | 1 |
